Outdoor Full Color Nation Star P4 P5 P6 P8 P10 LED Display for Advertising Screen Panel Sign

• Tube Chip Color：Full Color
• IP Rating：IP65,IP54
• Pixel Pitch：8mm
• Pixel Configuration：SMD3535
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：400W,M2

=== Base Info ===

• Model NO.：P8 Outdoor LED Display
• Pixel Density：15625 Pixel ,M2
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertisement, Concert, Shopping, Mall
• Certification：CE, RoHS, CCC, FCC
• Product Name：P8 Outdoor LED Display
• IC：Mbi 5124,5153
• Color Temperature：6500-7000K
• Refresh Rate：1920-3840 Hz
• Brightness：Over 7000 CD,M2
• Controller：Nova Star ,Linsn ,Huidu
• Service Life：100000h
• Use Voltage：AC 90-240V
• Cabinet Size：960*960mm ,1024*1024mm
• Maximum Power Consumption：800W,M2
• Production Time：12-15 Working Days
• Remote Help：Engineer Engineer Ready for You
• Transport Package：Flight Case ,Wooden Case ,Carton
• Specification：256mm*128mm , 320*160mm
• Trademark：Honghui
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：3500 Sqm ,Month

=== Description ===
Waterproof Outdoor Full Color 7000 CD P6/P8/P10 LED Display for Advertising Sign1HD small pixel LED displayP1.5625 / P1.667/ P1.923/ P22Hot rental LED displayP3 /P3.91 /P4 /P4.81 /P5.953Outdoor fixed LED displayP4/P5 /P6 /P8 /P10 /P16 /P204LED Control SystemNova Star / LINSN /Colorlight /Listen5LEDNation Star /Kinglight LED Lamp /Epistar LED chip from Taiwan6ICMBI5124/5153 IC7Power supplyMeanwell / G-energy8Cabinet kindIron /Aluminum /Die-casting /Fiber Aluminum  1Pixel Pitch8 mm2Cabinet Size1024*1024 mm /768*768mm3Pixel density15625 dots/m24Color temperature6000K--8000K5Viewing angleH: 140; V: 1406Dead LED lamp rate≤0.1‰7Non-Flatness<0.2mm8Module interval<0.2mm9Packaging Gross Weight(KG)50 kg (Estimated data)10Packaging dimension1m*1m*1.2 m (6 cabinet in one case)11Max power/m21200 W/m212Brightness adjusted256 grade by auto-optic/color &8 grade by hand13Input signalRF, S-video, RGB, RGBHV, YUV, YC&Composition, etc14Life-span≥1 00, 000 hours15MTBF5, 000 hours16Frame frequency25 - 60 Hz / s17Refresh rate≥2, 000 Hz / s18Single Input(with video processor)HDMI, DVI, VGA, RF, S-Video, RGB,
RGBHV, YUV, YC&Composition, etc. 19Control Distance120 m (no repeating); Optical fiber
Transmission: 0.5km- 10km20Systems Operating PlatformWindows XP, Win 7, Win8, Win8.1, Win10
Functions:
1. High refresh rate: With NOVA STAR control system, no scanning line when photographed
2. High gray level: 256 RGB each, display 16.7M colors, vivid and perfect video effect
3. High resolution: The most apparent features of the new generation of LED display
4. Good color uniformity: With brand Lamp Nationstar and high refresh MBI5124 IC.
5. High Brightness: 6000-8000 CD/m2, brightness automatically adjusted
6. High Quality: CE, RoHS, FCC, UL, IP65, ISO9001 passed + 96 Hours serious testing time
7. Long life span: Over100, 000hours, warranty from 2 to 5 years.
8. You need = We design: Provide Personal- Customized LED offer


2. Product Details:






3. Application:
