=== Description ===
Part2: P2.5 P3 P3.91 P4.44 P4.81 P5.33 P6.67 Full Color Outdoor Front Service LED Advertising Display Screen image details ,
Part3: Material Quality Level
All of our Product materials we choose all top quality levels, including the SMD, IC components, also the PCB, screws, PSU brands etc, so that during the led screen using, it helps to cut down after sale serive costs, to make sure led display screen stable and less aftersale services.
Part 3: Technical Specification.
Item
Pixel Pitch
3.91mm-10mm
Pixel Density(pixels/M2)
10000-65536 pixels
Pixel Configuration
SMD 3 IN 1
Module size(mm)
320x320mm (options). 250x250mm
Module Resolution(pixels)
32*32 - 64x64 pixels
Min.Viewing Distance(m)
3-10m
Brightness(nits)
>6500
Viewing Angle(degree)
≤140°
Average Power Consumption(W/M2)
400
Scan Mode
Constant current
Protection Level
IP65/IP54
Cabinet Size(mm)
960x960mm / 750x500mm
Color Temperature
The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements
Input Voltage
AC110-240V, 50HZ|60hz
Refresh Rate
> 3840hz
Color
65535 Levels
Horizontal/Vertical viewing angle
<140°
Gray Scale
16 bits
Effective Communication Distance(without relay)
Lifespan
≥100,000 hours
Environment Temperature
Storage: -40°C~+85°C , Operation: -20 °C~+45°C
Blind Spot Rate
<0.0001(led display industry standard is less than 0.0003)
Control Mode
Video frequency synchronization
Part 5: Installation methods, outdoor front service back service LED Display screen fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.
Part6: Packing information by plywood cases, packing well and easy to load,
Part7: Certificates.
ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.
Part8: About LEDventure.
Part9 : LED display screen installation cases.
Most of our led display exported to Europe with high standards, and small percent to USA and Asia,
Address: LEDventure Buliding,Lebao Industrial Park,Fengxin RD,Guangming New District,Shenzhen,China.
