Outdoor Waterproof P8mm Perimeter Stadium High Brightness Full Color Advertising LED Display Panel

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：8mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：300W,Sqm

=== Base Info ===

• Model NO.：F1pro
• Pixel Density：15625dots,Sqm
• Scanning Mode：1,5 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, ETL, L,C
• Module Size：320X160mm
• Cabinet Size：960X960mm
• Cabinet Material：Die Casting Aluminum
• LED Type：SMD3535
• Refresh Rate：1920-3840Hz
• Screen Brightness：6000nits
• Protection Grade：IP65
• Viewing Angle：V:140° , H:140°
• Controller：Nova
• Maintenance：Rear Service
• Compliance：CE , RoHS ,CCC,FCC,ETL
• Avg.Power Consumption：260W,Sqm
• Max.Power Consumption：750W,Sqm
• Transport Package：Plywood Case
• Specification：960x960mm
• Trademark：CKGLED
• Origin：China
• HS Code：8528591090
• Production Capacity：6000sqm,Month

=== Description ===

NO.

Parameters

Specifications

1

Model:

F1pro

2

Pixel Pitch (mm):

8

3

Physical Density (dot/m2):

15625

4

LED Configuration:

1R1G1B

5

LED Type:

SMD3535

6

Module Size (mm x mm):

320x160

7

Module Resolution (PX x PX):

40x20

9

Drive Mode:

1/5 Constant Current Drive

10

Cabinet Size (mm x mm):

960x960mm

11

Cabinet Resolution (PX x PX):

120x120

12

Cabinet Material:

Die casting aluminum magnesium alloy

13

Cabinet Weight

32KG

14

Viewing Angle (Deg):

H: 140 / V: 140

15

Brightness (cd/m2):

6000

16

Grey Scale:

14bit

17

Refresh Rate (Hz):

1920

18

Power Consumption (W):

MAX.: 750 / AVE.: 260

19

Color (M):

>16.7

20

Input Voltage (V):

AC 100V~240V+/-10%

21

Refresh Frame Frequency (Hz):

60

22

Protection Level:

IP65

23

Working Temperature (ºC):

-30°- +70°

24

Operation humidity (RH):

10%-95%

25

Controller

Novastar

26

Certificates:

CCC ,CE,RoHS,FCC
