Perimeter Stadium Outdoor Full Color Advertising LED Display Board

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：6.67mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：300W,Sqm

=== Base Info ===

• Model NO.：6.67mm, 8mm, 10mm
• Pixel Density：22500dots,Sqm
• Scanning Mode：1,6 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, ETL, L,C
• Module Size：320X160mm
• Module Resolution：48X32dots
• Cabinet Size：960X960mm
• Cabinet Resolution：144X144mm
• Cabinet Material：Die Casting Aluminum Magnesium Alloy
• LED Type：SMD3535
• Refresh Rate：1920-3840Hz
• Screen Brightness：7000nits
• Protection Grade：IP65
• Viewing Angle：V:140° , H:140°
• Controller：Nova
• Maintenance：Rear Service
• Compliance：Ce , RoHS ,CCC,FCC,ETL
• Avg.Power Consumption：300W,Sqm
• Max.Power Consumption：900W,Sqm
• Transport Package：Plywood Case
• Specification：960x960mm
• Trademark：CKGLED
• Origin：China
• HS Code：8528591090
• Production Capacity：6000sqm,Month

=== Description ===

NO.

Parameters

Specifications

1

Model:

S06

2

Pixel Pitch (mm):

6.67

3

Physical Density (dot/m2):

22500

4

LED Configuration:

1R1G1B

5

LED Type:

SMD3535

6

Module Size (mm x mm):

320x160

7

Module Resolution (PX x PX):

48x24

9

Drive Mode:

1/6 Constant Current Drive

10

Cabinet Size (mm x mm):

960x960mm

11

Cabinet Resolution (PX x PX):

144x144

12

Cabinet Material:

Die casting aluminum magnesium alloy

13

Cabinet Weight

32KG

14

Viewing Angle (Deg):

H: 140 / V: 140

15

Brightness (cd/m2):

6000

16

Grey Scale:

16bit

17

Refresh Rate (Hz):

1920

18

Power Consumption (W):

MAX.: 900 / AVE.: 300

19

Color (M):

>16.7

20

Input Voltage (V):

AC 100V~240V+/-10%

21

Refresh Frame Frequency (Hz):

60

22

Protection Level:

IP65

23

Working Temperature (ºC):

-30°- +70°

24

Operation humidity (RH):

10%-95%

25

Controller

Novastar

26

Certificates:

CCC ,CE,RoHS,FCC
