P4 Indoor High Quality Advertising LED Display Billboard

• Tube Chip Color：Full Color
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Pixel Pitch：4mm
• Pixel Configuration：1R,1G,1B
• Pixel Density：62500 Pixels,M2
• Scanning Mode：1,16 Scan

=== Base Info ===

• Model NO.：IXII-P4S
• System Operating Platform：Windows
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP31
• Certification：CE, RoHS, UL, CCC, ETL
• Cabinet Material：Die Casting Aluminum
• Cabinet Weight：7kg,PCS
• Service Solution：Front Service
• IP Rate：IP31
• Viewing Distance：4 Meters
• Brightness：1000-2500nits
• Refresh Rate：1920-3840Hz
• Contrast Rate：3000:1
• Voltage：AC110-240V
• LED Lamps：Epistar
• PSU：MW
• Installation：Back Bolted Hanging
• Software OS：Windows
• System：Nova
• Transport Package：Plywood Cases
• Specification：640x480mm
• Trademark：LEDventure
• Origin：China
• HS Code：8528591090
• Production Capacity：2000sqm,Month

=== Description ===
Overview Product Mainly Features

Indoor Aluminum Wall Mounted Series LED Display Screen is a special series with ultra light weight aluminum cabinet, cabinet size is 640*480mm, 7KG per cabinet. Other sizes are optional, 640*640mm and 960*640mm. Hot selling products are P3 and P4, we can provide the best solution according to your project.

It is popular for indoor advertising media, such as in airport, shopping mall, shows etc. To ensure high quality product, we used non-rusting and light aluminum cabninet design, HD resolution with high contract rate and refresh rate.

Detailed Photos

Material Quality Level

All of our Product materials we choose all top quality levels, including the SMD, IC components, also the PCB, screws, PSU brands etc, so that during the led screen using, it helps to cut down after sale serive costs, to make sure led display screen stable and less aftersale services.





Product Parameters



Item

Indoor Aluminum Wall Mounted Series LED Display Screen

Model Number

IXII-P4S

Pixel Pitch

4mm

Pixel Density

62500 pixels/M2

Pixel Configuration

1R1G1B

LED Type

Epistar, SMD

Module Size

320x160mm

Module Resolution

80*40 pixels

Min.Viewing Distance

4 meters

Brightness

1000-2500nits

Viewing Angle(degree)

≤140°

Average Power Consumption

250 W/M2

Scan Mode

1/16 Scan

Protection Level

IP31

Cabinet Size

640x480mm, 640x640mm, 960x640mm



Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50Hz/60Hz

Refresh Rate

1920-3840HZ

Color

65535 Levels

Horizontal/Vertical viewing angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

<100 meters

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization

 Installation Instructions

Indoor led video wall available fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.




Packaging & Shipping

Packing by plywood cases, packing well and easy to load

Certifications

ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.
