Fixed High Contrast Ratio Lightweight Cabinet Outdoor Billboard LED Display

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：10.6 6mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：350 W,Panel

=== Base Info ===

• Model NO.：BDF-10
• Pixel Density：8,800 Px,M2
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, ETL
• LED Type：SMD 3535
• Brightness：>5500 Nits
• Refresh Rate：>1920 Hz
• Contrast Ratio：4000:1,2000:1
• Cabinet Material：Die Casting Aluminum
• Cabinet Weight：35kg
• Processing：16 Bits
• Colours：281 Trillion
• Viewing Angle：160°,140°
• Transport Package：Wooden Crate,Flight Case
• Origin：China
• HS Code：8528591090
• Production Capacity：6000m2,Month

=== Description ===

Basic Info.

Model NO. BDF-10 Pixel Density 8,800 Px/M2 Display Type LED Video Display Application Advertising Certification CE, RoHS, UL, CCC, ETL LED Type SMD 3535 Brightness >5500 Nits Refresh Rate >1920 Hz Contrast Ratio 4000:1/2000:1 Cabinet Material Die Casting Aluminum Cabinet Weight 35kg Processing 16 Bits Colours 281 Trillion Viewing Angle 160°/140° Transport Package Wooden Crate/Flight Case Origin China HS Code 8528591090 Production Capacity 6000m2/Month

Product Description

Fixed High Contrast Ratio Lightweight Cabinet Outdoor Billboard LED Display



Fixed High Contrast Ratio Lightweight Cabinet Outdoor Billboard LED Display Features

1. Release different information and advertisement,text, picture and video version optional

2. Die Casting aluminum cabinet for ultra lightweight and slim,about 30% lighter than normal steel cabinet

3.Standard design cabinet for covering pixel pitch among 2.6 to 10.6 mm

4.High and adjustable brightness,even in the direct sunlight, people can see clear image in far away.

5. New perspective optimization design, covering the mainstream audience.

6.Anti UV, anti deformation module suite to protect the screen body deformation.

7.Multiple waterproof casing design, single box full inspection factory, the protection level IP65 mature signal transmission architecture, equipped with the upgraded version of power management technology, the use of more secure and reliable.

8.Front and rear maintenance access.

Fixed High Contrast Ratio Lightweight Cabinet Outdoor Billboard LED Display Specification

Physical Pitch	8mm
Pixel Configuration	SMD2727
Pixel Density	15,625 pixels/m²
Module Dimensions	512×256mm
Panel Dimensions	1024×768×100mm
NO. of Modules Per Panel	2×3
Physical Resolution of Module	64×32dots
Physical Resolution of Panel	128×96dots
Panel Material	Die - Casting
Single Cabinet Weight	35kg
Grayscale	16bit
Colors	281trillion
Contrast Ratio	4000:1
Average Power Consumption	350W/ m²
Max Power Consumption	700 W/ m²
Refresh Rate	>1920Hz
Brightness	>5500nits
Expected Lifetime	100,000Hrs
Servicing	Front/Rear
IP Rating(Front/Rear)	IP65/IP54

Fixed High Contrast Ratio Lightweight Cabinet Outdoor Billboard LED Display Applications





  1. Wide color range, excellent color uniformity, no rainbow effect.
    2.Dustproof  and Waterproof of IP65,with -20°C - 60°C working temperature for outdoor display, adapted to the harsh environment.
      3. High contrast, High refresh rate and High brightness that the content on the display remains clearly visible under direct sunlight without any delay





 1.High-contrast of 4000:1 as well as refresh rate of 1920 hz can achieve a good display.
    2.Using distributed scanning technology and module design technology that make higher reliability&stability.
     3. The LED Chips that we use have the advantages of large viewing angle, low power consumption and good color uniformity.




Services

*  We can offer customization service for customized products and can provide onsite installation and testing service.

* We provide 2 years warranty and free repair service for our products sold.

*  We also provide free training to customers' engineer.

* From raw materials to every process, we have strict production and testing process to ensure that our products under the quality inspection system standards.

* At the same time, we have an aging testing of 72 hours as well as waterproof test of outdoor led display to ensure the high quality of the product.

Tips

*  Payment: We accept the L/C, T/T, Western Union.

* Shipment: We will ship within 30 working days after you placed the order, but the specific delivered time will be affected by the shipping company and shipping details.

* Package: We usually pack the product in a wooden box or flight case.
