Single rod cylinder
CD
02
Series
H1
Types of mounting
03
Swivel eye at cylinder base
MP31)
Self-aligning clevis at cylinder base
MP5
Round flange at the cylinder head
MF3
Round flange at the cylinder base
MF4
Trunnion
MT42)
Foot mounting
MS2
04
Piston Ø (ØAL) 40 … 320 mm
...
05
Piston rod Ø Stroke length in mm3)
...
Design principle
07
Head and base flanged
A
08
Component series 30 ... 39 (30 ... 39: unchanged installation and connection dimensions)
3X
Line connection / version
09
According to ISO 1179-1 (pipe thread ISO 228-1)
B
According to ISO 9974-1 (metric thread ISO 261)
M
Flange connection according to ISO 6162-2 tab. 2 type 1 (≙ SAE 6000 PSI)
D4; 9)
Flange connection according to ISO 6164 tab. 2
H4)
according to ISO 1179-1 (pipe thread ISO 228-1) with flat pipe flange
C31)
For directional and high-response valves
Subplate NG6
P4; 5)
Subplate NG10
T4; 6)
Subplate NG16
U4; 7)
Subplate NG25
V4; 8)
For SL and SV valves
Subplate NG6
A4; 5; 15)
Subplate NG10
E4; 6; 15)
Subplate NG20
L4; 7; 15)
Subplate NG30
N4; 8; 15)
Line connection/position at cylinder head
10
View to piston rod30)
Line connection/position at cylinder base
11
View to piston rod30)
Piston rod design
12
Hard chromium-plated
C
Hardened and hard chromium-plated
H12)
Nickel-plated and hard chromium-plated
N19)
Piston rod end
13
Thread for swivel head CGAS
A
Thread for swivel head CGA, CGAK, plain clevis CSA
G13)
With With With With End position cushioning
14
Without Both sides, self-adjusting
D1)
Both sides, adjustable
E
Seal design
15
For mineral oil HL, HLP and oil-in-water emulsion HFA
Standard seal system
M
Standard seal system with guide rings
L
Reduced friction
heavy industry
R
For mineral oil HL, HLP, oil-in-water emulsion HFA and water glycol HFC
Standard seal system HFC
G
Servo quality/reduced friction
T
Chevron seal kits
A
For HDFR phosphate ester and HFDU polyol ester
Servo quality/reduced friction
S
Standard seal system FKM
V
Chevron seal kits
B
Option
16
Additional options, fill fields for additional options
Z
Without 18
Without additional guide rings
W
Additional guide rings
F10; 28)
19
Without measuring coupling
W
Measuring coupling, on both sides
A
20
Standard conical grease nipple, DIN 71412 Form A
W
Spherical bearing, maintenance-free
A 21
Without piston rod extension
W
Piston rod extension "LY", specify in mm in plain text
Y
22
Priming class CP3
W
Painting class CP4
B21)
Painting class CP5
L21)
Painting class CP6
U21)
Painting class CP7
E21)
23
Without oil filling
W
With oil filling
F
24
Without test certificate
W
With acceptance test certificate 3.1 based on EN 10204
C
1) | Only piston Ø 40 … 200 mm |
2) | Trunnion position freely selectable. When ordering, always specify the "XV" dimensions in the plain text in mm |
3) | For max. available stroke length see Technical data and for admissible stroke length (according to the kinking calculation) see Project planning information. |
4) | Not possible with MF4 |
5) | Piston Ø 40 … 80 mm, only position 11, subplates only possible in combination with line connection "B" at the head |
6) | Piston Ø 63 … 200 mm, only position 11, subplates only possible in combination with line connection "B" at the head |
7) | Piston Ø 125 … 200 mm, only position 11, subplates only possible in combination with line connection "B" at the head |
8) | Only piston Ø 160 … 200 mm, only position 11, subplates only possible in combination with line connection "B" at the head |
9) | Only piston Ø 80 … 320 mm |
10) | Seal designs A, B not possible; piston Ø 220 … 320 mm standard |
12) | Only piston rod Ø 22 … 140 mm |
13) | Not with piston Ø 320 mm |
14) | Not possible with piston rod end "N" |
15) | Subplates for SL and SV valves (isolator valves) Please note: Seal designs T, G, L, R, S and V are not designed for the static holding function! |
19) | Only piston rod Ø 45 … 160 mm |
21) | Specify RAL color in the plain text |
28) | With seal design "L" standard |
30) | All graphical representations in the data sheet show position 1 |
31) | With MS2, only position 11 is possible |
34) | With MF4 and line connection B, M or C not possible |
35) | Not possible with MP3 |
37) | Min. stroke length = 20 mm |
Order example: | |
CDH1MP5/100/56/300A3X/B11CADMW | |
CDH1MP5/100/56/300A3X/B11CADMZ EWABWWWW |
