Rexroth Cdm1cgm1 Csm1 Cdh3 Cgh3 Csh3 Hydraulic Cylindermill Type High Temperature and High Pressure, Metallurgical Cylinder Rexroth

Shenzhen Y&F INTR CO., LTD. / 2022-06-27

Pressure：High Pressure
Work Temperature：High Temperature

=== Base Info ===

Model NO.：CGH3
Acting Way：Double Acting
Working Method：Rotary
Adjusted Form：Switching Type
Structure：Rack and Pinion Type
Material：Carbon Steel
Transport Package：Carton and Wooden Box
Specification：30-30-50
Trademark：yuken
Origin：China
HS Code：8412909090
Production Capacity：10000
Package size per unit product：40.00cm * 10.00cm * 10.00cm
Gross weight per unit product：10.000kg

=== Description ===

Single rod cylinder

Series

Types of mounting

Without

Rectangular flange at cylinder head

MF1²⁾

Rectangular flange at cylinder base

MF2²⁾

Round flange at the cylinder head

MF3

Round flange at the cylinder base

MF4

Swivel eye at cylinder base

MP3

Self-aligning clevis at cylinder base

MP5

Trunnion

MT4³⁾

Foot mounting

MS2

Piston Ø (ØAL) from 25 ... 200 mm; see Technical data

...

Piston rod Ø (ØMM) 14 … 140 mm; see Technical data

...

Stroke length in mm

...

Design principle

Head and base flanged

Component series 20 … 29 (20 … 29: unchanged installation and connection dimensions)

Line connection / version

Pipe thread according to ISO 1179-1

Metric ISO thread (DIN/ISO 6149-1)

Enlarged pipe thread according to ISO 1179-1; see Dimensions

S^4;5)

Rectangular flange connection according to ISO 6162; see Dimensions

F^5;6)

Square flange connection according to ISO 6164; see Dimensions

H^5;7)

For directional and high-response valves; see Dimensions

Subplate NG6

P^5;8;13)

Subplate NG10

T^5;9;13)

Subplate NG16

U^5;10;13)

For SL and SV valves¹⁴⁾; see Dimensions

Subplate NG6

A^5;8;13)

Subplate NG10

E^5;9;13)

Subplate NG20

L^5;10;13)

Line connection/position at cylinder head

View to piston rod¹⁶⁾

Line connection/position at cylinder base

View to piston rod¹⁶⁾

Piston rod design

Hard chromium-plated

Hardened and hard chromium-plated

H¹¹⁾

Stainless steel, hard chromium-plated

Piston rod end

Thread (ISO 6020-1) for swivel head CGKD

Thread (VW standard) for swivel head CGKD

H¹⁵⁾

Internal thread; see dimensions

E¹²⁾

Piston rod end "H" with mounted swivel head CGKD

F¹⁵⁾

Piston rod end "G" with mounted swivel head CGKD

End position cushioning

Without

Both sides, self-adjusting

Head sides, self-adjusting

Base sides, self-adjusting

Both sides, adjustable

Seal design

Suitable for mineral oil according to DIN 51524 HL, HLP

Standard seal system

Servo quality/reduced friction

T⁷⁾

Chevron seal kits

A⁶⁾

Suitable for phosphoric acid esters HFR

Standard seal system

Servo quality/reduced friction

S⁷⁾

Option 1

Without

Measuring coupling, on both sides

Inductive proximity switches

Option 2

Without

With piston rod extension "LY" in mm

Y¹⁷⁾

¹⁾	Only available upon request
²⁾	Piston Ø 25 … 125 mm
³⁾	When ordering, always specify the "XV" dimensions in the plain text in mm (see order example)
⁴⁾	Piston Ø 63 … 200 mm
⁵⁾	Not for MF2; MF4
⁶⁾	Piston Ø 50 … 200 mm
⁷⁾	Piston Ø 40 … 200 mm
⁸⁾	Piston Ø 40 … 80 mm, only position 11
⁹⁾	Piston Ø 63 … 200 mm, only position 11
¹⁰⁾	Piston Ø 125 … 200 mm, only position 11
¹¹⁾	Piston rod Ø 14 … 110 mm
¹²⁾	Piston rod Ø 22 … 140 mm
¹³⁾	Subplates only possible with pipe thread (ISO 1179-1)
¹⁴⁾	Subplates for SL and SV valves (isolator valves) Please note: Seal designs T and S are not designed for the static holding function!
¹⁵⁾	Per piston Ø only possible with large piston rod Ø
¹⁶⁾	All graphical representations in the data sheet show position 1
¹⁷⁾	When ordering, always specify the piston rod extension dimension "LY" in the plain text in mm (see order example)
	Order example:
	CDM1MT4/50/28/550A2X/B11CGDMWW, XV = 175 mm
	CDM1MF3/200/140/950A2X/B11CHKAWW
	Note:
	Replacement cylinder for series 1X
	In case of exchange with series 2X, you also have to exchange the bearing blocks (trunnions)!
