Potato Chips Production Line Potato Chip Machine

• Certification：CE, ISO9001
• Power Source：Electric
• Process：Thermal Processing
• Automatic Grade：Automatic
• Application：Chips
• Customized：Customized

=== Base Info ===

• Model NO.：TSSP-1
• Material：Food Grade Stainless Steel
• Frying Temperature：0-300 Degrees Celsius
• Fried Time：2min
• Automatic：Full
• Output：50-200kgs,Hour
• Voltage：380V,50Hz
• Power：180-200kw
• Type：Complete Line
• Working Type：Continuous
• Total Power：17-43kw
• Transport Package：According to Customer Requirement
• Specification：Customized
• Trademark：Ambitious
• Origin：China
• HS Code：8438600000
• Production Capacity：20sets,Year

=== Description ===

Basic Info.

Model NO. TSSP-1 Material Food Grade Stainless Steel Frying Temperature 0-300 Degrees Celsius Fried Time 2min Automatic Full Output 50-200kgs/Hour Voltage 380V/50Hz Power 180-200kw Type Complete Line Working Type Continuous Total Power 17-43kw Transport Package According to Customer Requirement Specification Customized Trademark Ambitious Origin China HS Code 8438600000 Production Capacity 20sets/Year

Product Description

1.- Potato Chips Production Line Making Plant Potato Chip Machine

Introduction of the potato chips:

Potato chips (British English:Crisps, American English:Potato Chips)are snack food made from fresh potatoes.

Potato chips are thin slices by cutting fresh potatoes, then fried,seasoned into crisp snacks,delicious and have become one of the most popular snacks in the world and has developed a variety of flavors.

Nowadays,potato chip is an important part of snack food in lots of countries and areas.


 Introduction of the potato chips machine and production line:

The potato chips machine line is an advanced snack food processing equipment. It integrates
the advantages of all kinds of individual machines, easy to be operated, powerful and investment
saving.
There're four types of produciton lines classified by the output(kgs/hour), small output capacity needs smaller area and lower cost, and normally semi-autmatic. Bigger output capacity
needs bigger layout and higher cost, you can choose the suitable one based on your total budget.



The factors affecting the oil content of potato chips:

1. The higher the density, the lower the moisture content of potato chips before frying, and the potato chips after frying.The lower the oil content. It is proved that the moisture content of potato slices can be reduced by 25% and the oil content of fried potato chips can be reduced by 6-8%.

2. The thinner the chips, the higher the oil content.

3. The higher the oil temperature, the lower the oil content of potato chips. With the increase of oil temperature, the density and viscosity of oil decrease, and the oil storage per unit space also decreases.

4. Different types of frying oil will also affect the oil content of potato chips.

5. In a certain period of time, the longer the frying time, the higher the oil content of potato chips.








The drawing of the potato chips/crisps production line:








2.-Applications of Potato Chips Production Line Making Plant Potato Chip Machine

Mainly for frying potato chips, french fries, banana chips, and so on.
Types: Semi-automatic, full automatic.







3.-Details of Potato Chips Production Machine Line


Output	50kgs/hr	100kgs/hr	150kgs/hr	200kgs/hr
Factory Layout(Min)	100m2, length 12m	250m2, length 18m	600m2, length 50m	800m2, length 70m
Electric Required	43KW	17KW	29KW	34KW
Gas Required	N/A	6m3	11m3	16m3
Edible Oil Required	80L/lot	470L/lot	550L/lot	830L/lot
Labor Required	2	4	6	8
Raw Potatoes Material	250kgs	500kgs	750kgs	1000kgs

4.-Production, Packing & Shipment

A).Packing:With wrapped film, or in wooden case.
B).Transportation: Sea containers, train, or other types.








5.-Company Summary

Zhucheng Tianshun Machinery Co.,Ltd. has grown into a large, specialized food machinery manufacturing enterprise which integrates R & D and manufacturing. Currently has more than 100 employees, the division of labor is professionalization and specific, there are technical department, after-sales service department, domestic marketing department, international business department, etc. The company has all kinds of welding equipment, machining equipment to meet the needs of different customers.


Main products: Food machinery and complete production lines, including:

Vegetables&fruits cutting machines,
Peeling&washing machines,
Frying equipment,
Air drying machinery,
Blanching&cooking machine,
Seasoning machine,
Food starching machine,
Vacuum packing machine,
Complete potato chips/french fries production line,plantain chips production line,
Donuts machine.

All of them can be designed semi-automatic and full automatic, and widely used for processing varieties of vegetable, fruits, fish, seafood, etc. Some of them have pass the CE certificate. All of them could be customized, and we also provide and design individual machines for customers.
