High Performance Gearbox 90 Degree K Series Helical-Bevel Gear Reducer

  • Application:Motor, Machinery
  • Function:Change Drive Torque, Speed Changing, Speed Reduction
  • Layout:Right Angle
  • Hardness:Hardened Tooth Surface
  • Installation:Horizontal Type
  • Step:Four-Step

=== Base Info ===

  • Model NO.:K
  • Type:Bevel Gear
  • Rated Power: 0.18kw-200kw:Max.Torque: up to 50000n.M
  • Gear Arrangement: Hardened Helical-Bevel:Shafts Position: Right Angle
  • Ratio: 5.36-178.37:Installation Form:Foot; Flange;Shaft Mounted
  • Housing: Cast Iron:Gears: Helical-Bevel Gears
  • Gearing Arrangement:Bevel Helical
  • Output Torque:up to 50000n.M
  • Input Speed:1400rpm
  • Output Speed:Based on Ratio
  • Ratio:5.36~178.37
  • Material of Housing:Cast Iron
  • Gear Material:20crmnti Alloy Steel
  • Mount Position:Foot, Flange, Shaft Mounted
  • Input Form:Motor, Motor Flange, Input Solid Shaft
  • Output Form:Solid Shaft, Hollow Shaft
  • Lubrication:Oil-Bath and Splash Lubrication
  • Transport Package:Wooden Case; Carton; Pallet
  • Specification:ISO; CE; SGS
  • Trademark:AOKMAN DRIVE
  • Origin:China
  • HS Code:8483409000
  • Production Capacity:50000

=== Description ===
Overview Product Description

Detailed Photos

K series gear units are available in the following designs:
KAZ..Y..Short-flange-mounted helical-bevel gear units with hollow shaft
K...Y...Foot-mounted helical-bevel gear units with solid shaft
KAT...Y...Torque-arm-mounted helical-bevel gear units with hollow shaft
KAB...Y...Foot-mounted helical-bevel gear units with hollow shaft
K(KF,KA,KAF,KAB,KAZ)S...Shaft input helical-bevel gear units
KA...Y...Helical-bevel gear units with hollow shaft
KA(K, KF ,KAF, KAB ,KAZ)R..Y..Combinatorial helical-bevel gear units
KF...Y...Flange-mounted helical-bevel gear units with solid shaft
KA(K, KF ,KAF ,KAZ)S...R...Shaft input combinatorial helical-bevel gear units
KAF...Y...Flange-mounted helical-bevel gear units with hollow shaft
KA(K, KF ,KAF, KAB ,KAZ)...Y...When equipping the user's motor or the special one ,the flange is required to be connected
High Performance Gearbox 90 Degree K Series Helical-Bevel Gear Reducer

The weights are mean values, only for reference.
Maximum torque means the biggest one of the maximum torque related to the different ratio for the specified size.

Rated Power:0.18KW~200KW
Rated Torque:Up to 50000N.m
Gear Arrangement:Bevel Helical Hardened Gearbox
Input Speed:50HZ or 60HZ of 4Pole,6Pole and 8pole motor
Ratio:5.36~192.18
High Performance Gearbox 90 Degree K Series Helical-Bevel Gear Reducer

Product Parameters

Structure:

K      KA           KF          KAF        KAZ          KAT           KAB                        Input power rating(kw)
 0.18~
3.00.18~
3.00.18~
5.50.18~
5.50.37~
110.75~
221.3~
303~
457.5~
9011~
16011~
20018.5~
200Ratio5.36~
106.385.81~
131.876.57~
145.157.14~
44.797.22~
192.187.19~
197.278.95~
175.478.74~
141.938.68~
146.0712.66~
150.0317.35~1
64.4417.97~
178.37Maximum
Torque(N.m)
 200400600820155027704300800013000180003200050000
Gear unit weight:Packaging & Shipping

High Performance Gearbox 90 Degree K Series Helical-Bevel Gear Reducer

Company Profile

High Performance Gearbox 90 Degree K Series Helical-Bevel Gear ReducerHigh Performance Gearbox 90 Degree K Series Helical-Bevel Gear Reducer

After Sales ServiceFAQ

1. How to choose a gearbox which meets our requirement?
You can refer to our catalogue to choose the gearbox or we can help to choose when you provide
the technical information of required output torque, output speed and motor parameter etc.
2. What information shall we give before placing a purchase order?
a) Type of the gearbox, ratio, input and output type, input flange, mounting position, and motor information etc.
b) Housing color.
c) Purchase quantity.
d) Other special requirements.
3. What industries are your gearboxes being used?
Our gearboxes are widely used in the areas of textile, food processing, beverage, chemical industry,
escalator,automatic storage equipment, metallurgy, environmental protection, logistics and etc.
4.Do you offer any visiting?
Yes! We sincerely invite you to visit us! We can pick you from airport, railway station and so on. Also, we can arrange housing for you. Please let us know in advanced.

5.Is your quality good?
Quality never tell lies, we're theprofessional manufacturer and exporter of gear reducer and motor in Asia, who has been given license since 1982. Also, we had achieved ISO9001 and CE Certificate among all manufacturers.

If you are interested in our product, welcome you contact me.
Our team will support any need you might have.
