High Precision Servo Planetary Gearbox Planetary Gear Reducer

• Application：Motor, Machinery, Marine, Agricultural Machinery
• Hardness：Hardened Tooth Surface
• Installation：Vertical Type
• Layout：Coaxial
• Gear Shape：Bevel Gear
• Step：Single-Step

=== Base Info ===

• Type：Planetary Gear Reducer
• Transport Package：Carton Box
• Specification：size 90
• Trademark：Newgear
• Origin：China
• HS Code：8483402090
• Production Capacity：300, 000 Set Per Year

=== Description ===

Basic Info.

Type Planetary Gear Reducer Transport Package Carton Box Specification size 90 Trademark Newgear Origin China HS Code 8483402090 Production Capacity 300, 000 Set Per Year

Product Description

High Precision Servo Planetary Gearbox Planetary Gear Reducer


*One-piece construction,High Precision and large output torque.
*Double bracing cage planetary shelf structure.high reliable. Can suit reversible rotation frequently
*Helical gear transmission, more reliable. Higher torque.
*Low return backlash, high precision.
*Special Rotation frame structure.can carry bigger Radial&Axial load


Size 42-180
Ratio:3-100
Backlash rank:
P1:1-3arcmin
P2:3-5arcmin
1,Imported material, Long life.
2,High  rigidity, Low noise.
3,High precision, High torque.


Characteristic:
(1) Low Noise:The use of helical gear design,to achieve a smooth,quite operation of the reducer.
(2) High Precision:Backlash is 3 arcmin or less,accurate positioning.
(3) High Rigidity,High Torque:The output shaft used large size,large span double support bearing design,which improves the rigidity and torque of the reducer.
(4) High Efficiency:1-stage up to 95% or more,2-stage up to 92% or more.
(5) Maintenance-Free:Low grease wear,can be lifetime lubrication.
(6) Sealing Effect is Good:Lubricating grease with high viscosity,not easy to separate the characteristics,ip65 protection class to ensure that no grease leakage.
(7) Installation Unrestrained:Can be installed arbitrarily.
(8) Wide Applicability:Applicable to any type of servo motor.
(9) An organic [integral] whole output axis.

Quality inspection procedure:
We have 20 QC/QA workers.10 strict QC processes including incoming materials QC, IPQC  10 Ageing test QC100% products will go through a 24-hours ageing test QC)before shipping.
Package;

Or we can make the neutral package as customer's request.
