Full Color Outdoor Curtain LED Display Screen Panel for Advertising

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：P20 mm
• Pixel Configuration：1r1g1b, DIP 346
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：180W , m²

=== Base Info ===

• Model NO.：P20 LED display screen
• Pixel Density：2500 Dots,M2
• Scanning Mode：Static Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, CCC
• Product Name：Curtain LED Display
• Bightness CD/Sqm：7000CD,M2
• Grey Scale：65536 Degree
• Life Time：More 100, 000 Hours (80%)
• Mtbf：More 50, 000 Hours
• Operating Temperature：-30~-60t
• Humidity：10%-95%
• Transport Package：Wooden Case Flight Case and Carton
• Specification：500*1000 mm
• Trademark：hongking
• Origin：Shenzhen China
• HS Code：8528591090
• Production Capacity：5000 Sqm,Year

=== Description ===

Basic Info.

Model NO. P20 LED display screen Pixel Density 2500 Dots/M2 Scanning Mode Static Scan Display Type LED Video Display Application Advertising Certification CE, RoHS, CCC Product Name Curtain LED Display Bightness CD/Sqm 7000CD/M2 Grey Scale 65536 Degree Life Time More 100, 000 Hours (80%) Mtbf More 50, 000 Hours Operating Temperature -30~-60t Humidity 10%-95% Transport Package Wooden Case Flight Case and Carton Specification 500*1000 mm Trademark hongking Origin Shenzhen China HS Code 8528591090 Production Capacity 5000 Sqm/Year

Product Description

Full Color Outdoor Curtain LED Display Screen Panel for Advertising

brightness 7000CD/m2
Average power 130W/m2
Unit  cabinet  Weight 10kg/pcs
 If you have interests in buying, pleased send A complete inquiry need to show:
1. led screen panel pixel pitch, if you dont know how to choose, contact us
2. led screen size:length ___m; width___m,or cabinet quantity;
3. use for indoor or outdoor;  fixed installation or rental?
4. intallation place pictures will be better;

• Contact person : Phebe
• Mobile phone: 00 86 177 2460 2807

 product description :

Pixel Pitch	P20 mm
Density (dots/sqm )	2500dots
Horizontal spacing(mm)  vertical  spacing(mm)	20MM  20MM
LED  lamp	DIP 346
cabinet Size	500*1000mm
cabinet  Resolution	25*50dot
cabinet Weight (kg/pcs)	17KG
Frame  Weight (kg/M2)	8KG
Installation thickness (cm) Frame+ cabinet	12.4CM
Transparent  Rate(%)	50%
LED/IC Configuration	Standard
Brightness	7000cd/m2
Viewing angle	110° H and  110°V
Control Method	Synchronous or   Asynchronous
Average Power Consumption	130 W/m2
Max Consumption	400W/m2
Best viewing distance	10-200m
Refresh Rate	2880HZ

Professional production:
Full Color LED Display, Indoor LED Display, Outdoor LED Display, Rental LED Display, Outdoor SMD LED Display, Outdoor DIP LED Display, Full Color LED Display Module, Single Color LED Display Module, Transparent LED Display, Advertising LED Screen

Company descripition:
HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress. Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. HONGKINGLED products are approved by CE, CCC, EMC and FC. We are fully certified by ISO standards.
