- Tube Chip Color:Full Color
- IP Rating:IP65
- Pixel Pitch:16mm
- Pixel Configuration:1R, 1G, 1B
- Display Function:Video Display
- Average Power Consumption:300W , m²
=== Base Info ===
- Model NO.:P16
- Pixel Density:10000 dot , m²
- Scanning Mode:1,4 Scan
- Display Type:LED Video Display
- Application:Stage Performance, Advertising, Shopping Guide
- Certification:CE, CCC
- Warranty Period:2years
- Deliver Time:15-20 Days
- LED Package:DIP 546
- Drive Type:Constant Drive
- Modle Size:256mm*128mm
- Life Span:100000 Hours
- Brightness:7000
- Transport Package:Simple and Easy Cabinet
- Specification:1024*1024mm*80mm
- Trademark:FWS
- Origin:Shenzhen China
- HS Code:9405409000
- Production Capacity:500square ,Month
=== Description ===
Tehnical parameter
Panel | Dimension | 256mm*128mm |
Pixel pitch | 16mm |
Pixel Density | 3906 DOTS/M2 |
Pixel resolution | 16*8 |
Pixel configuration | 1R1G1B |
LED specification | DIP 546 |
Average power | 45W |
Panel weight | 0.5 KG |
Cabinet&Bracket | Best viewing distance | 110/90 |
Cabinet size(W*H*T) | 1024MM*1024MM*80MM |
Cabinet Weight | 45 KG/sqn |
Best viewing angle | 8-100 Meter |
Module quantity | 12 pcs |
Panel power supply | 5V40A |
Screen power supply | AC220V-AC250V |
Electric current | ≤20 mA |
Max power | 800 W/Square |
Working temperature | -20ºC+50ºC |
Viewing Angle | 110ºC |
Average power | 450 W/sqn |
Tehnical parametr | Driving device | 16126 Constant current driving |
Drive type | 1/4 Scanning |
Refresh frequency | 1200HZ adjustable |
Display color | 6500K-9500K |
Brightness | 7000 mcd/M2 |
Operating Humidity | 10%-90% |
Refresh Rate | 300 HZ |
Control Method | synchronized with computer monitor |
Life span | 100000 Hours |
Communicaion distance | <100 Meter |
Effect Show Packaging&shipping Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible.
