Indoor/Outdoor SMD P2.6/P2.9/P3.91/P4.81 Full Color LED Display Screen for Stage Rental

• Tube Chip Color：Full Color
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Pixel Pitch：3.91mm
• Pixel Configuration：1R,1G,1B
• Pixel Density：65410 Dots,M2
• Scanning Mode：1,16 Scan

=== Base Info ===

• Model NO.：P3.91mm
• System Operating Platform：Winxp,Win2000,Win98
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP31
• Certification：CE, RoHS, UL, CCC, ETL
• Module Size：250X250mm
• Maintenance：Front , Rear
• Cabinet Size：500*500*88mm,500*1000*88
• Screen Brightness：1600nits
• Refresh Rate：1920Hz
• Module Resolution：64*64dots
• Cabinet Resolution：128X128dots , 128X256dots
• Controller：Nova,Colorlight,Linsn
• Transport Package：Flight Case
• Specification：500*500*88mm
• Trademark：CKGLED
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：6000sqm,Month

=== Description ===
NO.ParameterSpecifications1ModelRII-32Pixel Pitch(mm)3.913LEDSMD20204Screen Resolution65536dots/sqm5Scan Method1/166Cabinet size(L*H*W)500x500x88mm7Cabinet(Kg)15KG8Viewing angleH:140° V:140°9Grey Scale14bits10Refresh rate(HZ)≥192011Module size(mm)250*25012Brightness(nits)≥120013Working Voltage(V)AC 100~240V14AVE. power consumption (W/sqm)20015MAX. power consumption(W/sqm)60016IP gradeIP31 17controllerNovastar18Working humidity10~95%RH19Input VoltageAC 110V-220V +/-10%20Frame requency60Hz21Working temperature-30ºC~60ºC22ComplianceCCC / CE / UL/ RoHS
CABINETS PHOTOS:




Oversea Completed Case




Facory room:





48 hours LED modules burning test



72 hours Whole LED display screen testing



CERTIFICATION:




Package :

1. Flight case package (For rental):




2. Wooden case Package(for fixed install):





Pre-producing:

1. Get complete requirements of clients
2. To do a thorough analysis
3. Offer a most reasonable and scientific solution
4. Customized design

In producing:

1. Producing progress updating for clients
2. Particular Installation CAD and Design Diagram for clients

After service:

1. 2 years warranty.

2. 1% Free spare will be provided.

3. 7 days a week, 24 hours a day on-line service for any technical support for any customers.

4. Free training for customers in factory.

5. Local Partner Installation Service.
