2022 New Product Indoor Display Screen P1.87 Advertising LED Displays

Hangzhou Awesome Imp&Exp. Co., Ltd. / 2022-06-27

2022 New Product Indoor Display Screen P1.87 Advertising LED Displays

  • Tube Chip Color:Full Color
  • Display Function:Video Display, Image & Text Display, Text Display, Market Display
  • Pixel Pitch:1.8mm
  • Pixel Configuration:1R,1G,1B
  • Pixel Density:284444 Dots,M2
  • Scanning Mode:1,32 Scan

=== Base Info ===

  • Model NO.:UHD-P1.87S
  • System Operating Platform:WIN XP
  • Display Type:LED Video Display
  • Application:Stage Performance, Advertising, Shopping Guide
  • IP Rating:IP43
  • Certification:CE, RoHS, UL, CCC, ETL
  • Cabinet Material:Die Casting Aluminium
  • Brightness:800-1000nits
  • Refresh Rate:3840Hz
  • Voltage:AC110-240V
  • LED Lamps:Epistar
  • Driver IC:Mbi
  • PSU:MW
  • Contrast Rate:3000:1
  • System:Nova
  • Transport Package:Plywood Cases
  • Specification:600x337.5mm
  • Trademark:LEDventure
  • Origin:China
  • HS Code:852859109
  • Production Capacity:2000sqm,Month

=== Description ===

Item

Indoor HD Series LED Display Screen

Model Number

UHD-P1.87S

Pixel Pitch

1.87mm

Pixel Density

284444 pixels

Pixel Configuration

SMD 3 IN 1

LED Type

NS, SMD

Module Size

150 x 337.5 mm

Module Resolution

80 * 180 pixels

Min.Viewing Distance

2 m

Brightness

800-1000 nits

Viewing Angle

≤140°

Average Power Consumption

160 W/M2

Scan Mode

1/32 Scan

Protection Level

IP43

Cabinet Size

600 x 337.5 mm

Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50Hz/60Hz

Refresh Rate

3840hz

Color

65535 Levels

Horizontal/Vertical viewing angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

<100 meters

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization



Part 5: Installation Methods

Indoor Outdoor LED Display screen fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.
2022 New Product Indoor Display Screen P1.87 Advertising LED Displays
2022 New Product Indoor Display Screen P1.87 Advertising LED Displays


Part 6: Packing Information

Packing by plywood cases, packing well and easy to load
2022 New Product Indoor Display Screen P1.87 Advertising LED Displays
Part 7: Certificates.

ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.
2022 New Product Indoor Display Screen P1.87 Advertising LED Displays



Part 8: About LEDventure.

2022 New Product Indoor Display Screen P1.87 Advertising LED Displays
Part 9: LED Display Screen Installation Cases.

Most of our led display exported to Europe with high standards, and also exported to USA, South America and Asia
2022 New Product Indoor Display Screen P1.87 Advertising LED Displays
2022 New Product Indoor Display Screen P1.87 Advertising LED Displays
