Sintering Powder Metallurgy Small Metal Planetary Gearbox

Ningbo Yinzhou Wenhui Paper Co., Ltd. / 2022-06-27

Sintering Powder Metallurgy Small Metal Planetary Gearbox

  • Application:Motor, Electric Cars, Motorcycle, Machinery, Marine, Toy, Agricultural Machinery, Car
  • Function:Distribution Power, Clutch, Change Drive Torque, Change Drive Direction, Speed Changing, Speed Reduction, Speed Increase
  • Layout:Cycloidal
  • Hardness:Hardened Tooth Surface
  • Installation:Vertical Type
  • Step:Three-Step

=== Base Info ===

  • Model NO.:Metal Gearbox
  • Type:Planetary Gear Box
  • OEM:Yes
  • Metal Fabrication:Steel
  • Motor:Brush Motors 3V , 6V , 12V , 24V , 36V
  • Transport Package:Air Bubble Bag, Box, Carton
  • Specification:as customers requirement
  • Origin:China
  • Production Capacity:800, 000pieces ,Month

=== Description ===

Basic Info.

Model NO. Metal Gearbox Type Planetary Gear Box OEM Yes Metal Fabrication Steel Motor Brush Motors 3V , 6V , 12V , 24V , 36V Transport Package Air Bubble Bag, Box, Carton Specification as customers requirement Origin China Production Capacity 800, 000pieces /Month

Product Description

Our main products, geared motors ,steel gearboxes ,gear systems for motors .
We specialize in designing and manufacturing highly engineered, custom gear motors ,gearbox parts ,and assemblies. Our professional staff are geared towards providing customers with high quality products and excellent service .

In a simple planetary gearbox setup, input power turns the sun gear at high speed. The planets, spaced around the central axis of rotation, mesh with the sun as well as the fixed ring gear, so they are forced to orbit as they roll. All the planets are mounted to a single rotating member, called carrier. As the planet carrier turns, it delivers low-speed, high-torque output. The Sun Gear Gets The Input While The 3 Planet Gears Provide The Ouput Via A Planet Carrier .

Gearbox ratio 3:1,5:1,10:1,20:1,30:1 , 50:1 , 100:1, etc.

Our gearbox,Light weight,small size, high carrying capacity, long service life .Smooth operation, low noise, large output torque, large speed ratio, high efficiency, power diversion, and multi-tooth meshing by powder metallurgy process .
 Customized metal parts specification

Product type
 Sintering planet metal gearbox with brushed /brushless /step motors, 5:1,10:1,20:1,30:1.50:1,80:1,100:1.200:1,500:1

Material
steel

Process
Powder metallurgy , metal injection molding ,machinery

Treatment
plating ,sand blasting , PVD , coating

Tolerance
±0.3%mm

Drawing format
DWG ,IGS , STP

Delivery time
10 days for mass production

Powder metallurgy (PM) is a metal parts / components fabrication way and made from metal powders material . The process of powder metallurgy (PM) is blending fine powder materials , press them into a desired shape or form compacting , and heating the compressed material in a controlled atmosphere to bond the material sintering .PM process can avoid , or greatly reduce the need to use metal removal processes,thereby drastically reducing yield losses in manufacture and oftern resulting in lower costs .
The powder metallurgy (PM) consist three steps : powder blending,compaction and sintering .Common products include gears , structural metal parts , bushings used for automobiles , appliances and powder equipments

Advantages of powder metallurgy
Products made by powder metallurgy (PM) generally do not need further finishing , because produces good surface finish.
Maintains close dimensional tolerances
Provides materials which may be heat treated for increased strength or enhanced wear resistance .
There is less wastage of raw material , can be very economical for mass production .
Complex shapes parts can be made . Provides controlled porosity for self-lubrication or filtration.
Suits to high volume parts productions requirements .


Custom metal parts
Sintering Powder Metallurgy Small Metal Planetary Gearbox
Sintering Powder Metallurgy Small Metal Planetary Gearbox
Sintering Powder Metallurgy Small Metal Planetary Gearbox

Sintering Powder Metallurgy Small Metal Planetary Gearbox

Workshop
Sintering Powder Metallurgy Small Metal Planetary Gearbox
Sintering Powder Metallurgy Small Metal Planetary Gearbox
Sintering Powder Metallurgy Small Metal Planetary Gearbox
