Gcan Support OBD2 Protocol USB Can Bus Adapter

Fuzhou Wasendar Paper Craft Products Co., Ltd. / 2022-06-23

Gcan Support OBD2 Protocol USB Can Bus Adapter

  • After-sales Service:Supplier Warranty
  • Warranty:12 Months
  • Certification:CE
  • Condition:New
  • Standard:Standard
  • Language:Spanish, Chinese, Japanese, German, French, English

=== Base Info ===

  • Model NO.:USBCAN-I Pro
  • Update Method:by Internet
  • Type:Engine analyzer
  • Working Temperature:-40~ 85ºC
  • Humidity:15 to 95%Non-Condensing
  • Can Channel:1
  • Can Connector:Open 4-Pin Terminal Block
  • Computer Interface:USB1.1, USB2.0, USB3.0
  • Baud Rate:5kbps~1Mbps
  • USB Interface:USB 2.0, Compatible with USB 1.1 and USB 3.0
  • Electric Isolation, Insulation Level:DC3000V
  • Receive Maximum Data Flow:14000 Fps
  • Transmit Maxinum:8000fps
  • Power Supply:USB Powered
  • Current:Max 130mA
  • Support Secondary Development:Yes
  • Electrical Isolation Protection Module:Integrated
  • Operating System:Windows XP, 7, 8, 10, etc
  • Transport Package:Carton
  • Specification:95x58x24mm
  • Trademark:GCAN
  • Origin:China
  • HS Code:8543709990
  • Production Capacity:10000

=== Description ===
Physical Size (LxWxH)98x58x24mmWeightapprox.90gOperating temeperature-40ºC~85ºCHumidity15 to 95% non-condensingConnectivity CAN channel1CAN connectorOpen 4-pin terminal blockCAN interfaceComopliant with CAN 2.0A, CAN 2.0, conform to ISO11898-2CAN baud rate5kbit/s to 1Mbit/sUSB interfaceUSB 2.0, compatible with USB 1.1 and USB 3.0IsolationDC 3000V electrical isolationReceive maxinum14000fpsTransmit maxinum8000fpsCAN resistor120Ω,select by Dip switchPower supply Power SupplyUSB poweredCurrent Max 130mASoftware Software supportECAN ToolsOperation systemWindows XP/7/8/10,etc and 32/64-bit LinuxDevelopment environmentVC,VB,.Net,Delphi,Labview,c++Builder
1.Automatic baud rate recognition function

It can automatically identify the baud rate of a bus with an unknown baud rate. As long as it is an active CAN bus, our company's equipment can identify its baud rate. There are two ways to identify the baud rate:
A: Standard baud rate recognition.(1000K, 500K, 250K...)
B: Full range of baud rate recognition.(set the start and end range, scan the baud rate in the range)
This function can send and receive data after identifying devices with unknown baud rate, and can also be used to test the baud rate of newly developed CAN communication devices.


Gcan Support OBD2 Protocol USB Can Bus Adapter
2.Basic CAN data transceiver function

The software can send and receive CAN bus standard data, support CAN2.0A, CAN2.0B frame format sending and receiving, support data frame, remote frame sending and receiving. The software receiving list can receive up to 1 million frames of data, and the receiving list can be saved locally in 3 formats-text file (.TXT), batch file (.CAN), excel file (.csv), this function is convenient The user performs data storage and processing analysis, and the batch file can be sent back to the CAN bus through software.

Gcan Support OBD2 Protocol USB Can Bus Adapter

3.Advanced CAN bus data transmission function

When sending data, you can set the normal sending mode and the list sending mode. The list mode can edit multiple CAN data. The CAN data in the sending list can be sent simultaneously and cyclically, and the sending list can be saved/loaded.
The file sending function can send the batch file (.CAN) back to the CAN bus according to the time sequence information when receiving. The batch file can be edited through the notepad, and the edited file can be sent according to the content actually written by the user.
This function can be used as a signal simulator for automotive electronics users. For example, the car navigation is controlled by the CAN signal to turn on. The user can intercept a piece of data containing the car navigation startup signal without having to find the startup signal from these data. After removing the navigation from the car, resend this piece of data to the navigation to start the navigation without ECU.


Gcan Support OBD2 Protocol USB Can Bus Adapter
Gcan Support OBD2 Protocol USB Can Bus Adapter
Packing

Gcan Support OBD2 Protocol USB Can Bus Adapter
Gcan Support OBD2 Protocol USB Can Bus AdapterGcan Support OBD2 Protocol USB Can Bus AdapterFAQ

1. who are we?
We are based in Liaoning, China, start from 2010, sell to Domestic Market(70.00%). Southeast Asia(12.00%).South America(5.00%),Mid East(5. 00). Northern Europe(3. 00), Southern Europe(3.00%),Africa(2.00%).    There are total about 1150 people in our office

2. how can we guarantee quality?
Always a pre-production sample before mass production,
Always final Inspection before shipment.

3. what can you buy from us?
Controller, Data Analyzer, Converter

4. why should you buy from us not from other suppliers?
Our company has more 20 own intellectual-property rights with all of main products by ourselves, which is a leading supplier and service provider of industrial interconnection equipment in the country.

5. what services can we provide?
Accepted Delivery Terms: FOB, DDP,Express Delivery;
Accepted Payment Currency: USD, CNY;
Accepted Payment Type: T/T, Paypal. Cash;
Language Spoken: English, Chinese
