GS Series Solid Shaft Helical Worm Gear Motor for Sugar Roller Mills

• Application：Machinery, Marine, Agricultural Machinery, Industry
• Hardness：Hardened Tooth Surface
• Installation：Horizontal Type
• Layout：Coaxial
• Gear Shape：Bevel Gear
• Step：Single-Step

=== Base Info ===

• Model NO.：GS
• Type：Worm Reducer
• Weight：7kg - 240kg
• Ambient Temperatures：-10c - 40c
• Altitudes：1000m Above The Sea Level
• Running Direction：Clockwise and Anti Clockwise
• Transport Package：Plywood
• Specification：iSO9001: 2008
• Origin：Jiangsu
• HS Code：8483409000
• Production Capacity：30000 Sets,Year

=== Description ===
Data SeriesSpecifications 37 47 57 67 77 87 97 Ratio 6.8~288Input Power (Kw ) 0.12~22Output Torque(N.m)11~4530
Application fields
steel, chemical, oil, drink, food, electronic, process hides, pharmacy, and textile.
They are widely used in various low-speed transmissions, which are general basic parts of mechanical transmission.

Features

1.Highly Standard Modular Designed:The products are easily connected with and driven by different types of motors or other kinds of input power.The same type geared motor can be adapted to optioned powers of motors.It is therefore easy to realize different solutions for varied requirements.

2.Ratio:Featured many closely divided ratios and wide range of them.Very big final rations can be obtained through combined unites to reach extremely low output speeds.

3.Mounting Arrangement:No strict limitation to the mounting arrangement.

4.High Strength,Compact Dimension:Housings are made of high strength cast iron.Gears and shaft gears are finished with gas carburising process and precise grouding to sequeritially get high loading capacity of percertain volume.

5. Long Service Life: Under the condition of accurately selecting type size and the normal maintenance and use, main components (expect those easily-disabled parts) can last as long as up to more than 25,000 hours. Easily-disabled parts include lubricating oil, oil seals, and bearings.

6. Low Noise: All key components are finished by precisely machining, accurate assembly, and finally tested, and therefore, fairly low noise is reached.

7. High Efficiency: The efficiency of gear unit can reach 95%, The efficiency of worm gear unit can reach 89%.

8. Large radial loading ability.

9. Axial load ability of up to 5% of radial load.
