3500kgs High Rise Pneumatic Super Thin Scissor Lift for Wheel Alignment

• Type：Four Cylinder Hydraulic Lift
• Lifting Capacity：4T
• Driving Type：Hydraulic
• Certification：CE, ISO
• Driving Motor Number of Mechanical Lift：1
• Double Cylinder Lift Type：Planer-type

=== Base Info ===

• Model NO.：RS40W
• Shearing Lift Type：Big Shear Type
• Condition：New
• Brand：Rising Sun
• Design：Scissor
• Product Name：Pneumatic Super Thin Scissor Lift
• Max Lifting Height：1850mm
• Min Height：330mm
• Motor Power：2.2kw
• Oil Pressure：18MPa
• Lifting Time：50s
• Lowering Time：40s
• Power Supply：220-240V,380-415V,1,3pH,50,60Hz
• Color：Red,Blue,Grey,Customised
• Certificate：Ce
• Transport Package：7ctns, 1900kgs, 2cbm
• Specification：on ground scissor lift
• Trademark：RSISING SUN
• Origin：China
• HS Code：84254290
• Production Capacity：400sets,Month

=== Description ===

Basic Info.

Model NO. RS40W Shearing Lift Type Big Shear Type Condition New Brand Rising Sun Design Scissor Product Name Pneumatic Super Thin Scissor Lift Max Lifting Height 1850mm Min Height 330mm Motor Power 2.2kw Oil Pressure 18MPa Lifting Time 50s Lowering Time 40s Power Supply 220-240V/380-415V,1/3pH,50/60Hz Color Red,Blue,Grey,Customised Certificate Ce Transport Package 7ctns, 1900kgs, 2cbm Specification on ground scissor lift Trademark RSISING SUN Origin China HS Code 84254290 Production Capacity 400sets/Month

Product Description

3500KGS High Rise Pneumatic Super Thin Scissor Lift for Wheel Alignment

Sincerely looking for contracted distributor in different country,thanks for kind contacting !

Main feature

1. Luxurious scissor profile platform structure with super synchronization.
2. Device perform stable and reliable work is relayed on imported hydraulic pneumatic and electric components .
3. The pneumatic self-locking system and anti-explosion pipe structure are automatic opening when lowering which ensure the safety of the device.
4. Ingenious and unique sliding system and closed platform,also don't need ground pits.
5. With teolley guide rail and can optional add the second lifting trolley .
6. The position of the front wheel turning table(optional part ) is adjustable and suitable for various type of automobile .
7. With hydraulic lock and mechanical dual-gear safety-claw lock double safety device.Automatically open when lowering.By lock operation can has the safety-claw located adversely,safe&reliable.
8. CE certificated .


Technic data

Model	RS-40W
Lifting capacity	3500KG
Power supply	380V/50HZ/3PH
Motor	2.2KW
Max lifting height	(main)1800MM ,(jack)  490MM
Lowest height	180MM
Lifting time	55S
Air pressure	6-8BAR
Hydraulic pressure	25MPA
Length of platform	(main)4000MM, jack 880-1280mm

Our service
Warmly thanks for your any kind suggestion for our services and machine , we will improve better and better in the near future.
1) Warranty : 12months
    Free parts will be sent by courier or post  if machine goes wrong during 12months .
2) Delivery time : 10days after payent received .
3) 1set sample order is acceptable .
4) Method of payment : T/T , WESTERN UNION ,PAYPAL ,
5) Certificate : ISO , CE
