ISO9001 Waterproof LED Outdoor Factory Price 60W 80W 100W 120W Solar Street Light

• Light Source：LED Light
• Color Temperature(CCT)：Pure White
• Lamp Body Material：Aluminum Alloy
• Lamp Power：12-150W
• Power Supply：DC
• Average Life：>8000h

=== Base Info ===

• Model NO.：BD-0152
• Application：Highway, Square, Garden
• IP Rating：IP65
• Certification：CE, RoHS, CCC, ISO, FCC
• Voltage：12,24V
• Battery：Gel Battery
• Solar Panel：Polycrystal Monocrystal
• Height of Pole：4m-12m
• Controler：10A15A20A
• Cable：2.5mm2
• Transport Package：Bulk Package
• Trademark：LUYOU
• Origin：Yangzhou Jiangsu China
• HS Code：940540900
• Production Capacity：2000sets Per Month

=== Description ===
ParametersSolar ModulePmax(W)30-400W Vmp (V)35.0V Imp (A)2.86ALight FixtureMaterialAluminum die casting & Toughened glass Operating Temperature-40°C~75°C Protection LevelIP65LED Light SourceLED ChipBRIDGELUX / Cree (Top brand in U.S.A.) Color Temperature3800-6500K(white) Luminous flux5300 LM Operating temperature-40°C~75°C Current SourceDC 12V/24V Power15W/18W/21W/24W/30W/36W/42W/48W/54W/60WLighting PoleHeight3m/ 4m/ 5m/ 6m/ 7m/ 8m/ 9m/ 10m/ 11m/ 12 m MaterialBAOSTEEL GROUP Q235/345/GR60 Surface TreatmentHot-dip galvanizing, Static spray, Sizeφ60-φ200,δ3-5m, vary according to models Flange Plate300*300*16, vary according to modelsBatteryCapacity200AH (100AH*2pcs)  TypeGel/AGM Battery Dimension546*1203*30 Weight28KgControllerRated voltage and current12V/10A or 24V/10A waterproof  Weight0.165Kg Two times rainy day backup
&Protective FunctionTwo times of rainy day backup.
Good protection: overcharging, discharging, voltage surge, reverse polarity, etc.AccessoriesCable2.5 mm2, 15m Battery Box200AH ABS battery box or metal box with hot-dip galvanizing spray treatment Foundation KitDismountable foundation kit, saving in shippingTWO TIMES rainy day backup waterproof controller
Rainy day backup: 2 times more rainy day backup, savings in battery
Combined LED driver and controller as one, easy to maintain
IP67: ideal for high humidity and dust areas
Energy saving mode: THREE periods of power adjustment available
All metal shell: high strength and fast heat dissipation, giving long life time

UL LISTED GEL battery
Long service life (1600 cycles @ 30% DOD)
Better Weather-ability (-20 ºC ~ 50 ºC)
Fully sealed construction

SERVICES

WARRANTY
BAODE guarantees the purchaser for the period of two (2) years that BAODE's solar led lighting systems will be free from defects in materials and workmanship. BAODE will, at its option, repair or replace any BAODE's system that is defective for a minimum of two (2) years after the date of purchase.

INSTALLATION
BAODE offers detailed instructions and videos for installation of solar led lights. Besides, BAODE can provide onsite installation training and technical assistance free of charge in initial period for large projects more than 100 poles because we has developed her experienced technical team.

SPARE PARTS POLY
BAODE provides 0.5% to 1% of spare parts for free based on the transaction amount.
Transaction amount $1000 ~ $19,999
0.5% spare parts
Transaction amount more than $19,999
1% spare parts

AFTER SALES

*  BAODE will offer technical guidance and repair service for the whole life time of her products.
*  BAODE promises to respond with customer's questions within 24 working-hours.

Payment terms: 30% in advance and 70% before shipment.
Lead time: 2~3 weeks upon receipt of payment for 50 poles.
Shipping: Generally, solar lights are shipped by sea. Battery and pole are not available to ship by air.
Package: Individual package for each component of solar light. Wooden box for LED lamp and solar panel for LCL goods. 80 poles load a 40 HP container for 8M solar street lights and 60-3.5m solar garden lights in a 20 container.
