P5 Double Side Taxi Roof LED Screen

• Tube Chip Color：Full Color
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Pixel Pitch：5mm
• Pixel Configuration：1R,1G,1B
• Pixel Density：4000donts
• Scanning Mode：1,16 Scan

=== Base Info ===

• Model NO.：P5
• System Operating Platform：WIN XP
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP65
• Certification：CE, RoHS, UL, CCC, ETL, CF
• Life Span：100000 Hours
• Brightness：2800 Nit , Sqm
• Warranty Period：2years
• Deliver Time：15-20 Days
• Drive Type：Constant Drive
• Package Mode：SMD 2121
• Modle Size：320mm*160mm
• Color Display：Full Color
• Scaning Type：1,16 Scan
• Power Input：30W,Panel
• Transport Package：Wooden Case or Flight Case
• Specification：1200x450mm
• Trademark：FWS
• Origin：Shenzhen China
• HS Code：8528591090
• Production Capacity：25000 PCS ,Month

=== Description ===
LED LampTypeSMD 2121Arrangement1R1G1BLED ModulePixel Pitch5mmModule Resolution64×32=1024(Dots)Module Size320x160mmLED CabinetPixel Density4000 Dots/sqmThe entire screen size(W*H)1200×450mmCabinet Resolution192×64=12288(Dots) Module Quanty /Cabinet6×2=12(Pcs)Cabinet MaterialAcrylicCabinet Weight8kgBrightness>2800cd/sqmViewing Angle110(Horizontal),55(Vertical)Nearest Viewing Distance5mPower Consumption(Max)25W/HPower Consumption(Average)8W/HDisplay FunctionTextRefresh Rate>160HzDrive Mode/Driver PositionConstant driving 1/16 Scan,Combined diver boardFrame Frequencyno less than 60 frame/secInput VoltageDC12VOutput VoltageDC-5V,5A/10AGrey Scale LevelsNoBrightness Adjustmentcan be adjusted manually and automatically optionalMTBF( mean time between failures)5000 hoursLife-span100,000 hoursProtection Level(front/back)IP65Malfunction Dot Rateless than 0.003Working Temperature-15^oC~50^oCHumidity15%~85%Control SystemControl ModeAsynchronizationSoftwarePowerLed ( FWS-Huidu)LanguageChinese, Traditional Chinese, English, French, German, Japanese, Portuguese, Spanish, Turkish, Arabic, Persian, Mongolian, Thai.Control Card InputRS232/USBInput SignaltextPC Operating SystemMicrosoft Windows 10,Windows 7,and XPCommunication TypeRS232+USB/GSM/GPRS/GPRS+GPS location(available to purchase)CertificateCE,ROHS,FCC,ISO9001, TUVProduct Effects


Control method


 Features:
1.Independent power supply design features stable performance. Automatically disconnect to prevent screen burn when the current is too large or too small.
2.Concise and scientific cabinet design is with excellent shock-roof characteristic and easy to maintain.
3.Optokingdom adopt big brand chip and LED to manufacture led message sign with excellent stability and durability.
4.Multiple messages display in turn is available. Display time can be setup as your favor ((accurate to second).
5.The edited content can be stored on the control card and display according the order of play list.
6.High brightness ensure message can be seen within viewing distance even under strong sunshine.
7.It can easy to connect with the GPS terminal.
8.Support various control methods, such as USB,RS232,GPRS,GPS etc.
9.Suitable used for taxi roof led screen.
