Customized Van and Truck Painting Booth

• Type：Coating Production Line
• Certification：CE
• Substrate：Steel
• Brand：Sunrise
• Coating：Powder Coating
• Airflow Direction：Cross-flow Type

=== Base Info ===

• Model NO.：M17
• Heating Mode：Diesel
• Paint Mist Treatment：Dry-type
• Condition：New
• Length：17m
• Transport Package：Standard Export Packaging
• Specification：20M LENGTH
• Trademark：ORIENT
• Origin：China
• HS Code：84178090
• Production Capacity：100 Per Year

=== Description ===
Construction:Painting cabin with air extractionthrough the floor,
ceiling ventilation and intake air heating
construction of housing pre-fabricated elements for installation in an existing shed
further with working pit arranged in the middle and its ventilation.
 Operational modes:Effective space:Machine space dimensions:    Thermal energy:                   Gate assembly: One main door for drive in 4,27(W) x 5,38(H) meter2 personnel doors : 0,8(W) x 2,0(H) meter, with windows.Length of connections measured over edge floor:  Exhaust air lines  approx. + 10,00 meter over edge
Suction lines   approx. +  8,00 meter over edge
Flue pipes VA   approx. +  9,00 meter over edge
( Depending on the height of hall, perhaps further channels will be necessary. )Connected loads:Approx.  50 kW
Operating voltage:   400 volts, 50 Hz.
Control voltage:   230 volts, 50 Hz
