- Light Source:LED Light
- Color Temperature(CCT):Cool White
- Lamp Body Material:Aluminum Alloy
- Lamp Power:40W
- Power Supply:Solar
- Average Life:>8000h
=== Base Info ===
- Model NO.:SMLN-40W
- Application:Highway, Square, Garden
- IP Rating:IP66
- Certification:CE, RoHS, ISO, FCC, EMC, GS
- Voltage:12V
- Lamp Luminous Efficiency(Lm/W):180lm,W
- Working Temperature(ºC):′-40ºC - 60ºC
- CRI (Ra>):75,80,85,90
- Working Lifetime(Hour):50000
- Beam Angle:150*70°
- Working Mode:Full Power and Dim Mode
- Lighting Area:100m²
- Lighting Time:12hrs Each Day
- Controller:MPPT
- Back up Days:3 Days
- Maintenance:8 Years Free Maintenance
- Mounting Height:3m 4m 5m 6m 7m
- LED Chip Brand:USA Bridgelux 210lm,W
- Lamp Luminous Flux(Lm):180
- Distance Between Poles:10-15m
- Transport Package:Carton
- Specification:886x450x140mm
- Trademark:sunmaster
- Origin:Zhejiang, China
- HS Code:9405409000
- Production Capacity:1000PCS,Week
=== Description ===
Basic Info.
Model NO.
SMLN-40W
Application
Highway, Square, Garden
IP Rating
IP66
Certification
CE, RoHS, ISO, FCC, EMC, GS
Voltage
12V
Lamp Luminous Efficiency(Lm/W)
180lm/W
Working Temperature(ºC)
′-40ºC - 60ºC
CRI (Ra>)
75/80/85/90
Working Lifetime(Hour)
50000
Beam Angle
150*70°
Working Mode
Full Power and Dim Mode
Lighting Area
100m²
Lighting Time
12hrs Each Day
Controller
MPPT
Back up Days
3 Days
Maintenance
8 Years Free Maintenance
Mounting Height
3m 4m 5m 6m 7m
LED Chip Brand
USA Bridgelux 210lm/W
Lamp Luminous Flux(Lm)
180
Distance Between Poles
10-15m
Transport Package
Carton
Specification
886x450x140mm
Trademark
sunmaster
Origin
Zhejiang, China
HS Code
9405409000
Production Capacity
1000PCS/Week
Product Description
1.3-5 rainy /cloudy days backup 2.Dusk-to-Dawn 12 hours with dim energy saving mode 3.Lighting times can be individually adjusted with program switch. 4.Illuminance in operation depending on local site conditions (average daylight available) and customer-specific lighting times.
Model NO. | SMLN-40W | Battery Type: | LiFePO4 27Ah/12.8V |
Power: | 40W | Charging Time: | 6-10 hours |
Color Temperature: | 6000-6500K | Discharging Time: | 10-12 hours |
Certificate: | CE/ROHS/IP65 | Product Dimension: | 886*450*140mm |
Viewing Angle: | 120 | Packing Dimension: | 940*510*200mm |
Working temperature : | ,-20 ~ +70 | Product Weight | 19kg |
Lamp Efficiency: | 70 lm/w | Material: | Aluminum Alloy |
Led chip brand: | USA Bridgelux LED chip | Install Height: | 6-7 m |
Solar Panel: | 18V 60W Mono-crystalalline | Warranty: | 3 years |
