Creative 33mm Thickness Gob LED Display Full Color High Resolution Indoor Digital LED Poster Showed at ISE for Shopping Mall

• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Pixel Pitch：1.7, 1.9mm, 2.5mm, 3mm

=== Base Info ===

• Model NO.：BP
• Pixel Configuration：1R,1G,1B
• Pixel Density：27,777 dots , m²
• System Operating Platform：More Operate System
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP40
• Certification：CE, RoHS
• Dimension：570mm*1897mm
• Contrast Ratio：4000:1
• Driving Method：1,27 Dynamic Scan
• Frame Rate：60 Fps
• Transport Package：Flight Case
• Specification：Aluminum
• Trademark：Bako Vision
• Origin：China
• Production Capacity：10000 M2,Month
• Package size per unit product：56.00cm * 189.00cm * 33.00cm
• Gross weight per unit product：28.000kg

=== Description ===

Basic Info.

Model NO. BP Pixel Configuration 1R,1G,1B Pixel Density 27,777 dots / m² System Operating Platform More Operate System Display Type LED Video Display Application Stage Performance, Advertising, Shopping Guide IP Rating IP40 Certification CE, RoHS Dimension 570mm*1897mm Contrast Ratio 4000:1 Driving Method 1/27 Dynamic Scan Frame Rate 60 Fps Transport Package Flight Case Specification Aluminum Trademark Bako Vision Origin China Production Capacity 10000 M2/Month

Packaging & Delivery

Package size per unit product 56.00cm * 189.00cm * 33.00cm Gross weight per unit product 28.000kg

Product Description

Creative 33mm thickness GOB LED Display Full Color High Resolution indoor Digital LED Poster showed at ISE for shopping mall


BP-GOB Series






 Specification



	BP-2.5-GOB
Physical Pitch	2.5 mm
Pixel Configuration	SMD 2020
Pixel Density	279,936pixels/m²
Module Dimensions (W × H)(mm)	280 × 210
Panel Dimensions (mm)	1890× 560 × 33
NO .of Modules Per Panel (W × H)	2 × 9
Physical Resolution of Panel (W × H)	729 × 216
Panel Material	Aluminum
Single Cabinet Weight	28kg
Processing	16 bit
Colours	281 trillion
Contrast Ratio	4,000 : 1
Average Power Consumption	250 W/ Set
Max Power Consumption	750 W / Set
Brightness	1,000 nits
Refresh Rate	≥3,840 Hz
Vertical Viewing angle	160°
Horizontal Viewing Angle	140°
IP Rating (Front/Rear)	IP40
Frame Rate	60 fps
Expected Lifetime	100,000 Hrs
Servicing	Front/Rear
Brightness level	Manually/Auto


What's different and similar between GOB and SMD Poster?








How to control the screen?






Our Service

1.Pre-sale service:
Reply enquiries in 24 hours.
Market research and forecast for customer.
Provide unique and professional solutions based on customer's requirement
Data sheet and samples offer.
Other services, such as special packing design, factory visiting and so on.

2.In-sale service:
Tracking report in producing.
Quality test report for every order.
Photos and videos as per customer's requirement.
Free spare parts.


3.After-sale service:
Lifetime free maintenance and upgrade.
Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
Customer satisfaction tracking report.
Free technician training.
Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
Special service for big project, such as stadium, exhibitions, squares and so on.


COMPANY INTRODUCTION

Shenzhen BAKO VISION Technology Co.,Ltd, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, is SHENZHEN BAKO LTD holding end professional customers among domestic and overseas markets.
Do not be hesitate to contact us if you have any quiry!




FAQ

Q1. Do you provide samples?is it free or extra?

A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q2.How to order?
A:Please send us your purchase order by Email or we can make you proforma invoice under your request.
We need to know the following information for your order before sending you PI.
1)Product information-Quantity,Specification(Size,Material,Technological if needed and Packing requirements etc.
2)Delivery time required.
3)Shipping information-Company name,Street address,Phone&Fax number,Destination sea port.
4)Forwarder's contact details if there's any in China.

Q3. Do you offer guarantee for the products?

A: Yes,we offer 2-5 years warranty to our products.
