High Quality Factory Directly Supply DAC Series Front Wheel Hub Bearing for Auto Parts/Car/Automotive/Auto Spare Part/BW Bearings DAC255200206
Dalian Refine Tech Co., Ltd. / 2022-06-24
- After-sales Service：yes
- Warranty：6 months
- Type：Wheel Hub Bearing
- Material：Chrome Steel
- Tolerance：P0 P6 P4 P5 P2
- Certification：ISO9001:2008
=== Base Info ===
- Model NO.：DAC255200206
- Clearance：C1 C2 C3
- ABS：Without ABS
- Brand：HENGLI, LZ
- Car Make：Benz
- Structure Type：Wheel Hub Bearing
- Vibration：V1 V2 V3 V4
- Precision Rating：P0 P6 P5 P4 P2
- Service：OEM ODM
- Main Market：Europe, North America, East Asia
- Seals Type：Open Z ZZ RS 2RS RZ 2RZ
- Shaft Diameter：42-90mm
- Transport Package：Neutral Packing,Customize
- Specification：0.19 Kg
- Trademark：HENGLI, LZ
- Origin：China
- HS Code：8482800000
- Production Capacity：150000 Pieces,Year
=== Description === We invested in two additional specialized bearing factories, which allow us to provide our clients with top of the line products such A - Manufacturer - Do it only with the Best; -Your Choice make different. Q2 - Our Products A - Spherical Roller Bearing, Cylindrical Roller Bearing, Needle Roller Bearing, Cam Followers, Thrust Bearing - Spherical Plain Bearing, Rod End, Ball Joint, Wheel Hub, Tapered Roller Bearing Q3 - Process of our production A - Heat Treatment - Grinding - Parts Inspection - Assembly - Final Inspection - Packing Q4 - How to customize bearing(non-standard) from your company? A -We offer OEM,Customized(Non-standard) service and you need to provide drawing and detailed Technical Data. Q5 - What should I care before installation? A - Normally, the preservative with which new bearings are coated before leaving the factory does not need to be removed; it is only necessary to wipe off the outside cylindrical surface and bore, if the grease is not compatible with the preservative, it is necessary to wash and carefully dry the bearing. -Bearings should be installed in a dry, dust-free room away from metal working or other machines producing swarf and dust. Q6 - How to stock and maintenance my bearings right? A - Do not store bearings directly on concrete floors, where water can condense and collect on the bearing; -Store the bearings on a pallet or shelf, in an area where the bearings will not be subjected to high humidity or sudden and severe temperature changes that may result in condensation forming; -Always put oiled paper or, if not available, plastic sheets between rollers and cup races of tapered roller bearings.
Boundary Dimensions (mm) Mass d D B C kg d D B C kg DAC20420030/29 20 42 30 29 0.23 DAC40720037 40 72 37 37 0.55 DAC255200206 25 52 20.6 20.6 0.19 DAC40720637 40 72.06 37 37 0.55 DAC25520037 25 52 37 37 0.31 DAC40730034 40 73 34 34 0.56 DAC25520040 25 52 40 40 0.35 DAC40740036 40 74 36 36 0.62 DAC25520042 25 52 42 42 0.36 DAC40740036/34 40 74 36 34 0.58 DAC25520043 25 52 43 43 0.36 DAC40740040 40 74 40 40 0.67 DAC25550043 25 55 43 43 0.44 DAC40740042 40 74 42 42 0.7 DAC25550045 25 55 45 45 0.46 DAC40750037 40 75 37 37 0.62 DAC25550048 25 55 48 48 0.48 DAC39(41)750037 39(41) 75 37 37 0.62 DAC25560032 25 56 32 32 0.34 DAC40750039 40 75 39 39 0.64 DAC25600045 25 60 45 45 0.48 DAC40750050 40 75 50 50 0.68 DAC25620048 25 62 48 48 0.5 DAC40760033/28 40 76 33 28 0.54 DAC27520042 27 52 42 42 0.33 DAC40760033 40 76 33 33 0.52 DAC27520043 27 52 43 43 0.33 DAC40760036 40 76 36 36 0.58 DAC27520045/43 27 52 45 43 0.34 DAC40760038 40 76 38 38 0.6 DAC27530043 27 53 43 43 0.34 DAC40760040/38 40 76 40 38 0.52 DAC27600050 27 60 50 50 0.56 DAC40760041/38 40 76 41 38 0.52 DAC28580042 28 58 42 42 0.47 DAC40760441/38 40 76.04 41 38 0.7 DAC28580044 28 58 44 44 0.48 DAC40800030.2 40 80 30.2 30.2 0.65 DAC28610042 28 61 42 42 0.56 DAC40800030.2 40 80 30.2 30.2 0.65 DAC29530037 29 53 37 37 0.35 DAC40800031 40 80 31 31 0.65 DAC30550026 30 55 26 26 0.26 DAC40800036/34 40 80 36 34 0.74 DAC30550032 30 55 32 32 0.28 DAC40800038 40 80 38 38 0.8 DAC30580042 30 58 42 42 0.4 DAC40800038.1 40 80 38.1 38.1 0.8 DAC30600037 30 60 37 37 0.42 DAC40800040 40 80 40 40 0.86 DAC30600337 30 60.03 37 37 0.42 DAC40800045/44 40 80 45 44 0.95 DAC30620038 30 62 38 38 0.52 DAC40820040 40 82 40 40 0.88 DAC30620048 30 62 48 48 0.56 DAC408402538 40 84.02 53.8 53.8 0.97 DAC30630042 30 63 42 42 0.57 DAC401080032/17 40 108 32 17 1.04 DAC30640042 30 64 42 42 0.49 DAC41680040/35 41 68 40 35 1.06 DAC30680045 30 68 45 45 0.58 DAC42720038 42 72 38 38 0.54 DAC32580065/57 32 58 65 57 DAC42720038/35 42 72 38 35 0.52 DAC32670040 32 67 40 40 0.61 DAC42750037 42 75 37 37 0.6 DAC32700038 32 70 38 38 0.62 DAC42760033 42 76 33 33 0.65 DAC32720038 32 72 38 38 0.64 DAC42760038/35 42 76 38 35 0.65 DAC32720345 32 72.03 45 45 0.6 DAC42760039 42 76 39 39 0.62 DAC34620037 34 62 37 37 0.41 DAC42760040 42 76 40 40 0.68 DAC34640034 34 64 34 34 0.43 DAC42760040/37 42 76 40 37 0.66 DAC34640037 34 64 37 37 0.47 DAC42770039 42 77 39 39 DAC34660037 34 66 37 37 0.5 DAC42780036/34 42 78 36 34 DAC34670037 34 67 37 37 0.5 DAC42780040 42 78 40 40 DAC35618031 35 61.8 31 31 0.42 DAC42780041/38 42 78 41 38 0.75 DAC35618040 35 61.8 40 40 0.43 DAC42780045 42 78 45 45 DAC35620031 35 62 31 31 0.35 DAC42800036 42 80 36 36 0.83 DAC35620040 35 62 40 40 0.43 DAC42800036/34 42 80 36 34 0.81 DAC35640037 35 64 37 37 0.46 DAC42800037 42 80 37 37 0.68 DAC35650035 35 65 35 35 0.4 DAC42800038 42 80 38 38 DAC35650037 35 65 37 37 0.51 DAC42800042 42 80 42 42 0.82 DAC35650045 35 65 45 45 0.6 DAC42800045 42 80 45 45 0.86 DAC35660032 35 66 32 32 0.42 DAC42800342 42 80 42 42 0.82 DAC35660033 35 66 33 33 0.43 DAC42820036 42 80 36 36 0.77 DAC35660037 35 66 37 37 0.48 DAC42820036 42 80 36 36 0.8 DAC35670042 35 67 42 42 0.6 DAC42820037 42 82 37 37 0.79 DAC35680233/30 35 68.02 33 30 0.47 DAC42840034 42 84 34 34 0.75 DAC35680037 35 68 37 37 0.52 DAC42840036 42 84 36 36 0.84 DAC35680042 35 68 42 42 0.62 DAC42840039 42 84 39 39 0.93 DAC35680039/36 35 68 39 36 0.56 DAC42840236 42 84.02 36 36 0.84 DAC35720027 35 72 27 27 0.48 DAC43/45820037 43/45 82 37 37 0.76 DAC35720028 35 72 28 28 0.49 DAC43760043/40 43 76 43 40 0.72 DAC35720228 35 72.02 28 28 0.49 DAC43760043 43 76 43 43 0.73 DAC35720233/31 35 72.02 33 31 0.54 DAC43770042/38 43 77 42 38 DAC35720033 35 72 33 33 0.58 DAC437745.5/41.5 43 77 45.5 41.5 DAC35720433 35 72.04 33 33 0.58 DAC43780044 43 78 44 44 DAC35720434 35 72.04 34 34 0.58 DAC43780045/44 43 78 45 44 DAC35720034 35 72 34 34 0.58 DAC43790041/38 43 79 41 38 0.77 DAC35720037 35 72 37 37 0.58 DAC43790045 43 78 45 45 0.84 DAC35720042 35 72 42 42 0.62 DAC43800038 43 80 38 38 0.75 DAC35720054 35 72 54 54 0.95 DAC43800040 43 80 40 40 DAC35720042 35 77 42 42 0.7 DAC43800045 43 80 45 45 0.91 DAC35720042 35 77 42 42 0.7 DAC43800050/45 43 80 50 45 0.91 DAC35800047 35 80 47 47 0.7 DAC43820045 43 82 45 45 0.96 DAC36680033 36 68 33 33 0.47 DAC43(45)820037 43(45) 82 37 37 0.76 DAC367629.2/27 36 76 29.2 27 0.55 DAC4482.50037 44 82.5 37 37 0.73 DAC36760029/27 36 76 29 27 0.55 DAC44840042/40 44 84 42 40 0.92 DAC37680034 37 68 34 34 0.52 DAC45770050/45 45 77 50 45 DAC37720033 37 72 33 33 0.58 DAC45800045 45 80 45 45 0.78 DAC37720037 37 72 37 37 0.59 DAC45830039 45 83 39 39 0.83 DAC37720237 37 72.02 37 37 0.59 DAC45840039 45 84 39 39 0.85 DAC37720437 37 72.04 37 37 0.59 DAC45840041/39 45 84 41 39 0.8 DAC37740037 37 74 37 37 0.61 DAC45840042/40 45 84 42 40 0.94 DAC37740045 37 74 45 45 0.79 DAC45840043 45 84 43 43 0.96 DAC38640032/29 38 64 32 39 DAC45840045 45 84 45 45 1 DAC38640036/33 38 64 36 33 DAC45840053 45 84 53 53 DAC38640036/33 38 64 36 33 DAC45850023 45 85 23 23 0.54 DAC38650052/48 38 65 52 48 DAC458500302 45 85 30.2 30.2 0.63 DAC38700037 38 70 37 37 0.56 DAC45850045 45 85 45 45 0.96 DAC38700038 38 70 38 38 0.57 DAC45850047 45 85 47 47 0.98 DAC38710033/30 38 71 33 30 0.5 DAC45850051 45 85 51 51 1.02 DAC38710039 38 71 39 39 0.58 DAC45870041/39 45 87 41 39 0.92 DAC38710233/30 38 71.02 33 30 0.5 DAC45880039 45 88 39 39 0.9 DAC38720036/33 38 72 36 33 0.56 DAC45900054/51 45 90 54 51 DAC38720236/33 38 72.02 36 33 0.56 DAC46780049 46 78 49 49 DAC38720034 38 72 34 34 0.55 DAC46800043/40 46 80 43 40 DAC38720040 38 72 40 40 0.63 DAC47810053 47 81 53 53 1.02 DAC38730040 38 73 40 40 0.67 DAC47850045 47 85 45 45 0.85 DAC38740036 38 74 36 36 0.62 DAC47880055 47 88 55 55 DAC38740036/33 38 74 36 33 0.61 DAC47880055 47 88 55 55 DAC38740236/33 38 74.02 36 33 0.59 DAC47880057.4 47 88 57.4 57.4 DAC38740040 38 74 40 40 0.67 DAC48860042/40 48 86 42 40 0.96 DAC38740050 38 74 50 50 0.85 DAC48890044 48 89 44 44 1.07 DAC38740450 38 74.04 50 50 0.85 DAC48890044/42 48 89 44 42 1.07 DAC38760043/40 38 76 43 40 DAC48900042 48 90 42 42 1.09 DAC38760043 68 76 43 43 DAC49840042/40 49 84 42 40 0.99 DAC38800236/33 38 80.02 36 33 DAC49840043 49 84 43 43 DAC39/41750037 39/41 75 37 37 0.62 DAC49840048 49 84 48 48 1.06 DAC39680037 39 68 37 37 0.48 DAC49840050 49 84 50 50 1.08 DAC39680637 39 68.06 37 37 0.48 DAC49880046 49 88 46 46 1.05 DAC39680737 39 68.07 37 37 0.48 DAC49900045 49 90 45 45 1.08 DAC39720037 39 72 37 37 0.6 DAC50900040 50 90 40 40 DAC39720037 39 72 37 37 0.6 DAC51890044/42 51 89 44 42 DAC39720637 39 72.06 37 37 0.6 DAC51910044 51 91 44 44 DAC39720040 39 72 40 40 0.61 DAC51960050 51 96 50 50 DAC39740036 39 74 36 36 0.54 DAC52910040 52 91 40 40 DAC39740036/34 39 74 36 34 0.52 DAC54900050 54 90 50 50 DAC39740039 39 74 39 39 0.66 DAC54920050 54 92 50 50 DAC39.1740036/34 39.1 74 36 34 0.66 DAC54960051 54 96 51 51 DAC40700043 40 70 43 43 0.63 DAC55900060 55 90 60 60
About Us
HENGLI Machinery Company is a well-established Chinese bearing supplier. We design, manufacture and wholesale bearings.
Our specialized manufacturer of Spherical Roller Bearing & Cylindrical Roller Bearing, LUAN Rolling Bearing Co., Ltd was
established in 1970 and is accredited by the Chinese Ministry of Machine Building.
as Needle Roller Bearings,Cam Follower Bearings,Thrust Bearings, Spherical Plain Bearings, Rod Ends Bearings, Ball
Joint Bearings, Tapered Roller Bearings, Wheel Hub Bearings and Non-Standard Bearings.
FAQ
Q1 - What is our advantages?
