Europe Standard Car Body Paint Cabinet Car Spray Booth for Sale

Kunshan Grepak Packing Materal Co., Ltd. / 2022-06-23

Europe Standard Car Body Paint Cabinet Car Spray Booth for Sale

  • After-sales Service:on Line Service
  • Warranty:12 Months
  • Type:Spray Booth
  • Certification:CCC, CE, CSA, GS
  • Substrate:Steel
  • Brand:Guangli

=== Base Info ===

  • Model NO.:GL
  • Coating:Powder Coating
  • Airflow Direction:Cross-flow Type
  • Heating Mode:Electric
  • Paint Mist Treatment:Dry-type
  • Condition:New
  • Transport Package:Iron Frame Packing and Carton Packing
  • Specification:External size (m) 7.0x5.6x3.5
  • Trademark:guangli
  • Origin:Guangzhou, China
  • HS Code:84198990
  • Production Capacity:40, 000 PCS,Year

=== Description ===

Basic Info.

Model NO. GL Coating Powder Coating Airflow Direction Cross-flow Type Heating Mode Electric Paint Mist Treatment Dry-type Condition New Transport Package Iron Frame Packing and Carton Packing Specification External size (m) 7.0x5.6x3.5 Trademark guangli Origin Guangzhou, China HS Code 84198990 Production Capacity 40, 000 PCS/Year

Product Description

Europe Standard Car Body Paint Cabinet Car Spray Booth for Sale

--Wall panel: Sandwich style, g=50mm, polystyrene, rock wool available as required.

--Basement: Steel structure, full grids, ramp: 2 PCS of grids.

--Door: 3 PCS of front door without aluminum side cover. 1PC of emergency door with pressure lock.

--One 11kw intake fan and one 11kw exhaust fan.

--4m straight exhaust ducts, one 90 degree bend, and one 60 degree bend. 4m straight chimney and 2 small bends.

--Electrical VCD. One pressure meter.

--Spraying/baking transition damper, automatically air controlled.

--Fire protection equipment: 1set, the inductor control closed; Energy-saving equipment: 1set.

--Heat exchanger: Stainless steel. Riello/ rg5s burner.

--Roof filter: 6 PCS of filter, mounted above support frame, which is made of steel and powder coated.

--5 PCS of floor filter and 2 PCS of outlet filter.

--Upper light: 10 sets, 4*40w per set. Side lights: 8sets, 4*40w.

--Control box: Imported components, overload, overheat, phase-lacking, phase-locking protection, engine y/ start...

--Automatically stop when preset time is up.

--Constant temperature spraying.
Equipment
Europe Standard Car Body Paint Cabinet Car Spray Booth for SaleExhibition
Europe Standard Car Body Paint Cabinet Car Spray Booth for SaleFactory Show
Europe Standard Car Body Paint Cabinet Car Spray Booth for Sale
ModelGL4000-A2
External size (m)7.0x5.6x3.5
Internal size (m)6.9x3.9x2.7
Entrance Width(M)3.0
Entrance Height(M)2.7
Fan capacity(m 3 /h)25000
Air velocity (m/s)0.3-0.5
Air ventilation (times/h)332
Max Drying Temperature60-80
Oil consumption (L/unit)6-8
Power (kw)25
Suitable Automobile TypeCar
