P4 Indoor Full Color HD Fixed Installation LED Display Screen

Danyang Yun Kai Metal Products / 2022-06-27

P4 Indoor Full Color HD Fixed Installation LED Display Screen

  • Tube Chip Color:Full Color
  • Display Function:Video Display
  • Pixel Pitch:4mm
  • Pixel Configuration:1R,1G,1B
  • Pixel Density:62500dots,Sqm
  • Scanning Mode:1,16 Scan

=== Base Info ===

  • Model NO.:4mm
  • System Operating Platform:Windows
  • Display Type:LED Video Display
  • Application:Stage Performance, Advertising, Shopping Guide, Shopping Mall, Concerts, Shows and Event, Airport
  • IP Rating:IP33
  • Certification:CE, RoHS, UL, CCC, ETL
  • Module Size:256X128mm
  • Module Resolution:64X32dots
  • Cabinet Size:512X512mm
  • Cabinet Resolution:128X128dots
  • Screen Brightness:1300nits
  • Refresh Rate:1920Hz-3840Hz
  • Compliance:Ce
  • Service:Rear Maintenance
  • Controller:Novastar, Linsn
  • Transport Package:Plywood Case
  • Specification:512x512mm
  • Trademark:CKGLED
  • Origin:China
  • HS Code:8528591090
  • Production Capacity:6000sqm,Month

=== Description ===

Basic Info.

Model NO. 4mm System Operating Platform Windows Display Type LED Video Display Application Stage Performance, Advertising, Shopping Guide, Shopping Mall, Concerts, Shows and Event, Airport IP Rating IP33 Certification CE, RoHS, UL, CCC, ETL Module Size 256X128mm Module Resolution 64X32dots Cabinet Size 512X512mm Cabinet Resolution 128X128dots Screen Brightness 1300nits Refresh Rate 1920Hz-3840Hz Compliance Ce Service Rear Maintenance Controller Novastar/ Linsn Transport Package Plywood Case Specification 512x512mm Trademark CKGLED Origin China HS Code 8528591090 Production Capacity 6000sqm/Month

Product Description


V SERIES PRODUCT FEATURES:

· Quiet fan design, excellent heat dissipation.,

· Sidelocks design for better consistency and seamless assembly.

· High polymer flexible mask, no mosaic phenomenon ,better contract ratio.

· High-performance metal plate cabinet, concise cable.

· The sealed-type back cover, effectively prevent wrong operations from the amateur.





PRODUCT SPECIFICATIONS:
NO.ItemParameters
1ModelV04
2Pixel Pitch (mm)4
3Physical Density (dot/m2)62500
4LED Configuration1R1G1B
5LED TypeSMD2020
6Module Size (mm x mm)256*128
7Module Resolution (PX x PX)64*32
8Module Power Consumption (W)26
9Drive Mode1/16 Constant Current Drive
10Horizontal Viewing Angle (Deg)140
11Vertical Viewing Angle (Deg)140
12Brightness (cd/m2)1,200
13Grey Scale14
14Refresh Rate (Hz)≥1920
15Cabinet Resolution (PX x PX)128*128
16Cabinet Max Power Consumption (W)750
17Cabinet Average Power Consumption (W)250
18Cabinet Size (mm x mm)512*512
19Cabinet Weight (Kg)26
20Cabinet Thickness (mm)120
21Cabinet MaterialSteel/Aluminum
22Color (M)>16.7
23Input Voltage (V)AC 110V~220V+/-10%
24Refresh Frame Frequency (Hz)60
25Protection LevelIP33
26Working EnvironmentIndoor
 27Working Temperature (ºC)"-20°- +40°
 28Operation humidity (RH)10%-90%
 29CertificatesCCC, CE,RoHS





LED Display Panel PHOTOS:

P4 Indoor Full Color HD Fixed Installation LED Display Screen




LED Display Project With CKGLED Brand:

P4 Indoor Full Color HD Fixed Installation LED Display Screen


P4 Indoor Full Color HD Fixed Installation LED Display Screen



 Package:

P4 Indoor Full Color HD Fixed Installation LED Display Screen


Certificates:
P4 Indoor Full Color HD Fixed Installation LED Display Screen
