Bevel Gear Box 90 Degree Km Series Small Hypoid Gearbox for Connveyor

Shinylink (Shanghai) Industrial Inc. / 2022-06-27

Bevel Gear Box 90 Degree Km Series Small Hypoid Gearbox for Connveyor

  • Application:Motor, Machinery
  • Function:Speed Changing, Speed Reduction
  • Layout:Orthogonal
  • Hardness:Hardened Tooth Surface
  • Installation:Industry
  • Step:Double or Three-Step

=== Base Info ===

  • Model NO.:KM
  • Type:Hypoid Gearbox
  • Rated Power:0.12kw-5.5kw
  • Input Speed:1400r,Min
  • Output Speed:4.7-187.0r,Min
  • Ratio:7.48-296.10
  • Output Torque:5.9-874n.M
  • Accessory:Torque Arm
  • Gear Housing:Cast Iron, Aluminum Alloys
  • Gearing Arrangement:Hypoid
  • Color:Customer′s Quest
  • Gear Material:20crmnti Steel
  • Housing Material:Aluminium Alloy,Cast Iron
  • Mount Position:Foot Mounted. Flange Mounted
  • Input Form:Mounting Motor
  • Service Power Range:Service Power Range
  • Warranty:1 Year
  • Transport Package:Wooden Case
  • Specification:ISO
  • Trademark:Aokman Drive
  • Origin:China
  • HS Code:8483409000
  • Production Capacity:3000PCS,Year

=== Description ===
Overview Product Description

Bevel Gear Box 90 Degree Km Series Small Hypoid Gearbox for Connveyor

Detailed Photos

2. KM series Helical-hypoid Gearbox's Main Materials
(1) Housing: die-cast aluminum alloy (frame size 27 to 57)
(2) Gear wheel: 20CrMnTiH1 carbonizing & quenching heat treatment make the hardness of gears surface be up to 56-62 HRC, and be retained carburization layers thickness between 0.3 and 0.5mm after precise grinding.
3. KM series Helical-hypoid Gearbox's Surface Painting
Aluminum alloy housing:
(1) Shot blasting and special antiseptic treatment on the aluminum alloy surface.
(2) After phosphating, spray the RAL9022 silver white paint.4.Gearbox Parameters
Bevel Gear Box 90 Degree Km Series Small Hypoid Gearbox for Connveyor
Bevel Gear Box 90 Degree Km Series Small Hypoid Gearbox for Connveyor

Product Parameters



KM0503 Stage50~3004.8~27130N.mΦ11Φ20, Φ24Φ252 Stage7.5~6024~181130N.mΦ11KM0633 Stage50~3004.6~27200N.mΦ11Φ25, Φ28Φ252 Stage7.5~6023~184200N.mΦ14KM0753 Stage50~3004.7~28350N.mΦ14Φ28, Φ30, Φ35Φ282 Stage7.5~6024~187350N.mΦ16KM0903 Stage50~3004.7~28500N.mΦ14Φ35, Φ38Φ352 Stage7.5~6024~187500N.mΦ19KM1103 Stage50~3004.7~27750N.mΦ19Φ40, Φ42Φ422 Stage7.5~6024~187750N.mΦ24Packaging & Shipping

Bevel Gear Box 90 Degree Km Series Small Hypoid Gearbox for Connveyor

Company Profile


Bevel Gear Box 90 Degree Km Series Small Hypoid Gearbox for Connveyor

Our Advantages


Bevel Gear Box 90 Degree Km Series Small Hypoid Gearbox for Connveyor

After Sales ServiceFAQ

1.Q:What kinds of gearbox can you produce for us?

A:Main products of our company: UDL series speed variator,RV series worm gear reducer, ATA series shaft mounted gearbox, X,B series gear reducer,
P series planetary gearbox and R, S, K, and F series helical-tooth reducer, more
than one hundred models and thousands of specifications
2.Q:Can you make as per custom drawing?
A: Yes, we offer customized service for customers.
3.Q:What is your terms of payment ?
A: 30% Advance payment by T/T after signing the contract.70% before delivery
4.Q:What is your MOQ?
A: 1 Set
