Transparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall Panel

Hainan (Yayuan) PPK Network Technology Co., Ltd / 2022-06-27

Transparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall Panel

  • Tube Chip Color:Transparent
  • IP Rating:IP65
  • Pixel Pitch:5.5*11,11*11,11*22,22*22
  • Pixel Configuration:1R, 1G, 1B
  • Display Function:Video Display
  • Average Power Consumption:80-800W,Square Meters

=== Base Info ===

  • Model NO.:LED-1
  • Pixel Density:2025-16200,DOT,Suqare Meters
  • Scanning Mode:High Speed 1 Scan
  • Display Type:LED Video Display
  • Certification:Non
  • Function:Sdk
  • LED Chip:SMD1812
  • Brightness:5000nits
  • Waterproof:IP65 Level
  • Media Available:Datasheet, Photo, Other
  • Pixels:5,6,8,10mm
  • Screen Material:Tempered Glass
  • Life Span:100000 Hrs
  • Transport Package:Box
  • Specification:32 inch, 80 inch, 75 inch, 86 inch, 50 inch, 65 in
  • Trademark:HOMEWELL
  • Origin:China
  • HS Code:85285910
  • Production Capacity:100000square Meters,Years

=== Description ===
Brand HOMEWELLPixel Pitch(mm) 5.5*11/11*11/11*22/22*22Screen Brightness 0-5000Gray Scale 256Drive Way High Speed 1 ScanOperating Voltage +5V DCScreen Material Tempered GlassOperating Temperature -20-55ºCStorage Temperature -40-80ºCWorking Humidity 10-90%Storage Humidity 5-95%


Transparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall Panel




Transparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall Panel



1. The TLD series adopts 2020GGB magic lantern beads, and is composed of unit modules

2. Any size LED display can be formed by splicing modules;

3. The light transmittance exceeds 80%, which does not affect indoor wind collection;

4. Wide voltage input power supply: AC90-264V 50/60Hz;

5. Support multiple file formats: display text, image, video and other screens;

6. Support mobile phone, computer file WIFI, 5G remote transmission;

7. The whole machine provides a 3-year quality guarantee;

8. Widely used in glass curtain wall, quantitative lighting, advertising media, space decora- tion, partition decoration, home design, commercial display, functional signage;
Transparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall Panel

1. Data transmission: According to the serial port or industrial Ethernet interface data, read the corresponding text, picture, video, and display the corresponding content.

2. Data update: Modify the display text, picture, video function through the serial port or industrial Ethernet interface.

3. Set parameters: The function of setting the display parameters through the serial port or industrial Ethernet interface; including: grayscale, color, brightness, display speed, screen split and merge, etc.

4. Storage function:Store display information, communication information, fault information, etc.

5. Read function:Read video transmission progress, store device content, send device data information, etc.

6. Power-on self-check function.
Transparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall Panel
Transparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall PanelTransparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall PanelTransparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall PanelTransparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall PanelTransparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall Panel

1. Do not hit the glass;

2. Pay special attention to the right angles, not to be impacted;

3. The brightness should not exceed 25% during debugging;

4. Ensure that the power supply is reliably grounded;

5. The power input line must not be heated or deformed during use;

6. Support audio output (the player comes with AUX3.5 interface, just connect the speaker)

7. The video signal line and power line between the transparent LED display must be connected during installation, otherwise it will be reworked;

8. For the setting of the play box, please refer to "Mobile APP Play Box Setting Instructions"

Transparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall Panel

1. Provide corresponding technical support and technical cooperation for the products sold, and guarantee 24-hour technical hotline service.

2. When installing and using the product, please strictly follow the installation instructions and precautions in the product manual, and install and use it in accordance with the product manual.

3.For common simple fault problems: YuGuang provides remote technical guidance through instant messaging tools such as telephone, email, and remote software to help solve

problems in the use of the equipment. Including but not limited to the connection problems of signal lines and power lines, system software problems of software use and

parameter setting, and replace-ment of modules, power supplies, and system cards.

Transparent LED Glass Screen Display Indoor/Outdoor Advertising Video Wall Panel

FAQ

1. May I know the Minimum order for your products?

    MOQ for transparent led display is 1sqm.



2. May I know the advantages of transparent LED Display?

Obvious advantages comapre to tranditional led facade and mesh led display:

1) 50%-94% transparency, no influence for window light and wind ventilating;

2) Only 16-18kg/m2, slim and light than die casting aluminumled panels;

3) Simplified led panel no need steel structure for fixation, save labour cost and a lot space;

4) Widely application for building glass wall, chain shop showcase, airport, expo center, stage, etc.



3. How to install the transparent led display?

Installation for transparent led display is so easy and simple, only tight cabinets quick lock, and install several steel tube to fix the whole led display from top side and bottom side.
