Vertical Fine Boring-Milling Machine T7240

Enping Yixinda Trade Center / 2022-06-23

Vertical Fine Boring-Milling Machine T7240

  • Certification:ISO
  • Transport Package:Wooden Case
  • Specification:SGS
  • Trademark:AMCO
  • Origin:Shaanxi Xi′an

=== Base Info ===

  • Model NO.:T7240
  • Production Capacity:20 Sets,Month

=== Description ===

Basic Info.

Model NO. T7240 Production Capacity 20 Sets/Month

Product Description

Vertical Fine Boring-Milling Machine T7240

The machine is mainly use for boring large and deep holes, (such as: cylinder body of locomotive, steamship, car)also can milling the surface of the cylinder. Servo-motor control the table longitudinal move and the spindle up and down. Spindle's whirl use variable-frequency motor to adjust the apeed, so it's can achieve of stepless speed change. Electricity of the machine are designed for PLC and man-machine interaction.
Max. boring diameterDia 320mm
Max. boring depth750mm
Spindle(carriage) travel1000mm
Spindle speed(stepless speed change for frequency conversion)50-1000r/min
(Spindle feed travel speed)6-3000mm/min
(Distance from spindle axis to carriage vitical plane)500mm
(Distance from spindle end-face to table surface)25-840mm
(Table dimension LXW)500x1600mm
(Table working slot)5        5slot
(Table longitudinal travel)1600mm
(Table longitudinal travel speed)6-3000mm/min
(Table latitudinal travel)300mm
Main-motor(Variable-frenquency motor)33HZ, 5.5KW
Table longitudinal travel motor (Serve motor)15Nm
Travel motor of spindle(Serve motor)15Nm
Boring dimension accuracyIT7
Milling dimension accuraryIT8
Rundness0.008mm
Cylindricity0.02mm
Boring roughnessRa1.6
Milling roughnessRa1.6-Ra3.2
Overall dimensions2281x2063x3140mm
N. W/G. W7500/8000KG
Vertical Fine Boring-Milling Machine T7240
Vertical Fine Boring-Milling Machine T7240
