Angular Contact Ball Bearing 71814 70*90*10mm Used in Machine Tool Spindles, High Frequency Motors, Gas Turbines 718 Series 719 Series H719 Series 70 Series

• Contact Angle：15°
• Aligning：Non-Aligning Bearing
• Separated：Unseparated
• Rows Number：Single
• Load Direction：Radial Bearing
• Material：Bearing Steel

=== Base Info ===

• Model NO.：71814
• Precision：P6 P5 P4 P2
• Applied to：Machine Tool Spindles, High Frequency Motors, Gas
• Transport Package：Wooden Box
• Specification：70*90*10mm
• Trademark：AUTO
• Origin：China
• Production Capacity：500000set,Year

=== Description ===

Basic Info.

Model NO. 71814 Precision P6 P5 P4 P2 Applied to Machine Tool Spindles, High Frequency Motors, Gas Transport Package Wooden Box Specification 70*90*10mm Trademark AUTO Origin China Production Capacity 500000set/Year

Product Description

Angular contact ball bearing 71814 70*90*10mm


71814 C 71814AC bearings
1036814 brass cage bearings
Materials Handling bearings

Product Description


Structure	Angular contact ball bearing
Item No.	71804
Internal Diameter	20mm
External Diameter	32mm
Width	7mm
Cr
Cor
Grease lubrication speed
Oil lubrication speed
Weight

Product Show





Factory
Luoyang Auto Bearing Co., Ltd. is located in Luoyang, which is one of the four great ancient capitals of China. Our company is the member of China Bearing Industry Association, and cooperating with State Quality Supervision and Testing Center for bearing. Our company is a professional bearing manufacturer which integrated with research ,development and marketing services.
Our major products include Deep Groove Ball Bearing, Spherical Roller Bearing, Slewing Ring, crossed Roller Bearing and other all kinds of high precision bearings. Our products are widely applied to motor industry, mining metallurgy, wind power generation, petroleum drilling, automobile and motorcycle etc..
Our company not only possesses advanced bearing manufacturing equipments and international first-class measuring instruments, but also has strong strength of manufacturing, inspecting and testing the high precision and reliability bearings. Each process is in strict accordance with the ISO9001 quality management system, which effectively guarantees the precise of products and stability of the performance. AUTO Bearings are mainly exported to the United States, South Korea, Europe, etc., which have reached the high level of foreign similar products.
The soul of our business culture is [Detail makes competitive, innovation makes first-class". We believe the production and management philosophy of [quality wins, casting competitive products". The company adheres to the zero-defect quality management for meeting customer requirements.







ITEM	SIZE (mm)
7000C	10*26*8
7001C	12*28*8
7002C	15*32*9
7003C	17*35*10
7004C	20*42*12
7005C	25*47*12
7006C	30*55*13
7007C	35*62*14
7008C	40*68*15
7009C	45*75*16
7010C	50*80*16
7011C	55*90*18
7012C	60*95*18
7013C	65*100*18
7014C	70*110*20
7015C	75*115*20
7016C	80*125*22
7017C	85*130*22
7018C	90*140*24
7019C	95*145*24
7020C	100*150*24
7021C	105*160*26
7022C	110*170*28
7024C	120*180*28
7026C	130*200*33
7028C	140*210*33
7030C	150*225*35
7200C	10*30*9
7201C	12*32*10
7202C	15*35*11
7203C	17*40*12
7204C	20*47*14
7205C	25*52*15
7206C	30*62*16
7207C	35*72*17
7208C	40*80*18
7209C	45*85*19
7210C	50*90*20
7211C	55*100*21
7212C	60*110*22
7213C	65*120*23
7214C	70*125*24
7215C	75*130*25
7216C	80*140*26
7217C	85*150*28
7218C	90*160*30
7219C	95*170*32
7220C	100*180*34
7221C	105*190*36
7222C	110*200*38
7224C	120*215*40
BS2562TN1	25*62*15
BS3062TN1	30*62*15
BS3072TN1	30*72*15
BS3572TN1	35*72*15
BS4072TN1	40*72*15
BS4090TN1	40*90*20
BS4575TN1	45*75*15
BS45100TN1	45*100*20
BS50100TN1	50*100*20
BS5590TN1	55*90*15
BS55100TN1	55*100*20
BS55120TN1	55*120*20
BS60120TN1	60*120*20
760205TN1	25*52*15
760206TN1	30*62*16
760207TN1	35*72*17
760208TN1	40*80*18
760209TN1	45*85*19
760210TN1	50*90*20
760211TN1	55*100*21
760212TN1	60*110*22
760305TN1	25*62*17
760306TN1	30*72*19
760307TN1	35*80*21
760308TN1	40*90*23
760309TN1	45*100*25
760310TN1	50*110*27
760311TN1	55*120*29
71900	10*22*6
71901	12*24*6
71902	15*28*7
71903	17*30*7
71904	20*37*9
71905	25*42*9
71906	30*47*9
71907	35*55*10
71908	40*62*12
71909	45*68*12
71910	50*72*12
71911	55*80*13
71912	60*85*13
71913	65*90*13
71914	70*100*16
71915	75*105*16
71916	80*110*16
71917	85*120*18
71918	90*125*18
71919	95*130*18
71920	100*140*20
71921	105*145*20
71922	110*150*20
71924	120*165*22
71926	130*180*24
71928	140*190*24
71930	150*210*28
71932	160*220*28
71800	10*19*5
71801	12*21*5
71802	15*24*5
71803	17*26*5
71804	20*32*7
71805	25*37*7
71806	30*42*7
71807	35*47*7
71808	40*52*7
71809	45*58*7
71810	50*65*7
71811	55*72*9
71812	60*78*10
71813	65*85*10
71814	70*90*10
71815	75*95*10
71816	80*100*10
71817	85*110*13
71818	90*115*13
71819	95*120*13
71820	100*125*13
71821	105*130*13
71822	110*140*16
H7000C-2RZ/P4	3.969
H7001C-2RZ/P4	3.969
H7002C-2RZ/P4	3.969
H7003C-2RZ/P4	3.969
H7004C-2RZ/P4	5.556
H7005C-2RZ/P4	5.556
H7006C-2RZ/P4	5.556
H7007C-2RZ/P4	6.35
H7008C-2RZ/P4	6.35
H7009C-2RZ/P4	6.35
H7010C-2RZ/P4	6.35
H7011C-2RZ/P4	7.938
H7012C-2RZ/P4	7.938
H7013C-2RZ/P4	7.938
H7014C-2RZ/P4	8.731
H7205C-2RZ/P4	7.938
H7206C-2RZ/P4	7.938
H7207C-2RZ/P4	8.731
H7208C-2RZ/P4	9.525



Packing

A. plastic box & outer carton & pallets
B. plastic bag & box & carton & pallet
C. tube package & middle box & carton & pallet
D. Depends on your needs

Delivery

A. Most orders will be shipped within 3-5 days of payment being received.
B. Samples will be shipped by cov2urier as FedEx,UPS,DHL,etc.
