1 Inch Single Digit 16 Segment LED Display with RoHS From Expert Manufacturer

• Tube Chip Color：Single Color
• Display Function：Numbers and Some Alphabets
• Pixel Pitch：7 Segments and Dp
• Pixel Configuration：7 Segments,PC
• Pixel Density：7 Segments,PC
• Scanning Mode：Static Scan

=== Base Info ===

• Model NO.：LD10013A,B
• System Operating Platform：Win
• Display Type：Segment LED Display
• Application：Shopping Guide, Meters and Instruments
• IP Rating：IP0
• Certification：RoHS, Reach
• Outline Dimensions：22.50X33.00X8.50mm
• Digit Height：1 Inch(25.4mm)
• Emitting Color：Single Color
• Dp Number：1PC
• Digit Number：1 Digit
• Chip Matrial：4-Element
• Transport Package：EPE Foam and Carton
• Specification：RoHS, REACH
• Trademark：LIGHTKEY
• Origin：China
• HS Code：8531200000
• Production Capacity：1000000PCS,Year

=== Description ===
Overview Detailed PhotosProduct Name

Features

Selection Guide



Single Digit 16 Segment LED Display, Digit Height:25.40mm(1.00 inch), External Dimensions: 23.00x33.00x14.80mm (L x W x H )Part No.ChipIV@IF=20mAIV@IF=20mACommon
CathodeCommon
AnodeMaterialColorWLDOne SegOne Seg A D G or DPMin.Typ.Min.Typ. LD10013AR LD10013BRGaAlAsSuper Red6401215810 LD10013AD LD10013BDGaAlAsHi-Red6402737.51825 LD10013AO LD10013BOGaAsPOrange62510.513.579 LD10013AY LD10013BYGaAsPYellow5881215810 LD10013AG LD10013BGGaPGreen56810.513.579 LD10013AUR LD10013BURAlGaInPUltra Red6404567.53045 LD10013AUO LD10013BUOAlGaInPUltra Orange62567.5904560 LD10013AUA LD10013BUAAlGaInPUltra Amber6054567.53045 LD10013AUY LD10013BUYAlGaInPUltra Yellow5954567.53045 LD10013AUG LD10013BUGAlGaInPUltra Green5734567.53045 LD10013APG LD10013BPGInGaNPure Green525180450120300 LD10013AUB LD10013BUBInGaNUltra Blue4704567.53045 LD10013AUW LD10013BUWSMDUltra White150180100120Unit:nmmcdmcdmcdmcd Available Options

Factory Overview



Our Services/Why choose Us

1. Professional service:  replied within 24 hours(at workdays).

2. Various ready moldings of lamp led are available: no need to afford extra fee for moldings.
3. We also can provide customized products, design according to your demand.

4. Reliable and stable quality: 100% testing for each piece. Automatic testing and bin code selection machine.
5. Experience: produce LED components for more than 14 years.
6. Advanced Equipment: ASM automatic production machines(biggest brand in LED automatic machines)
7. Concentration: We focus on LED research and development, production and sales.
