Carbide Cutting Tools with Excellent Endurance

• Coating：Uncoated
• Application：Combination Machine, Woodworking Machine
• Structure：Indexable Turning Tool
• Material：Cemented Carbide
• Type：Cutting Tool
• Size：Customized

=== Base Info ===

• Model NO.：Customized
• Length：Max. 1400mm
• Thickness：Min. 0.2mm
• Advantage：Long tool life
• Standards：Hra
• Style：Universal Tool
• Cutting Process：Turning Tools
• Work Type：Cut Off
• Transport Package：Carton Box
• Specification：ISO
• Trademark：Excelledge
• Origin：Chengdu, China
• HS Code：82090000
• Production Capacity：20, 000 PCS,Month

=== Description ===

Basic Info.

Model NO. Customized Length Max. 1400mm Thickness Min. 0.2mm Advantage Long tool life Standards Hra Style Universal Tool Cutting Process Turning Tools Work Type Cut Off Transport Package Carton Box Specification ISO Trademark Excelledge Origin Chengdu, China HS Code 82090000 Production Capacity 20, 000 PCS/Month

Product Description

We are a professional manufacturer of Cemented Carbide Tools, and can supply you with kinds of standard and special standard Cutting Tools.

The Cemented Carbide Tools is good at hardness and wear resistance, the tool life always is 3~10 times of the one made by tool steel. The cost-effective is obviously due to the long tool life.

The Cuttig Tools made by Cemented Carbide can be finishing proceed by CNC machines and EDM, so the cutting tools could be designed to different sizes and tolerances.
Recommended Grade of Tungsten Carbide Cutting Tools:

Grade	Density	Hardness (HRA)	Bending Strength (/Mpa)	Performance and Application	Equivalent ISO Grade
YG3X	15.0~15.3	92	1320	Fine Grain Size, outstanding in hardness, which is used to high speed finishing of cast iron, non-ferrous alloy, and  alloy hardened steel, and alloy steel.	K01
YG3	15.0~15.3	91	1200	Excellent in hardness, and suitable for finishing of cast iron, non-ferrous alloy, and plastic, rubber, etc.	K01
YG6X	14.6~15.0	91	1400	Fine grain size. Excellent in wear resistance.Be used to process ferrous steel (HB<200), glass, hard rubber, cardboard, marble, ceramic copper alloy etc.	K10
YG6	14.6~15.0	89.5	1450	Be used to process ferrous steel(HB<200),non-ferrous metal, wood, plastic, etc.	K20
YG8	14.5~14.9	89	1500	Rough and semi-finishing of cast iron, nonferrous metal, wood, plastic, etc.	K30
YG11C	14.0~14.4	86.5	2100	Grade for manufacturing nozzle, wear resistance parts, die insert, mining tool, measuring tool like gauge, micrometer etc	K40
YG15	13.9~14.2	87	2100	Grade for manufacturing nozzle, wear resistance parts, die insert, mining tool, measuring tool like gauge, micrometer etc	K40

The Cemented Carbide Cutting Tools also can be made according to your own specification.
