Outdoor High Quality P4 Advertising Board LED Display Screen

Hangzhou Awesome Imp&Exp. Co., Ltd. / 2022-06-27

Outdoor High Quality P4 Advertising Board LED Display Screen

  • Tube Chip Color:Full Color
  • IP Rating:IP65
  • Pixel Pitch:4mm
  • Pixel Configuration:1R, 1G, 1B
  • Display Function:Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption:350W , m²

=== Base Info ===

  • Model NO.:OF-P4
  • Pixel Density:62500 Pixels,M2
  • Scanning Mode:1,8 Scan
  • Display Type:LED Video Display
  • Application:Advertising
  • Certification:CE, RoHS, UL, CCC, ETL
  • Cabinet:Alu,Steel
  • Weight:35kg,50kg
  • Brightness:>6500nits
  • Refresh Rate:>3840Hz
  • Contrast Rate:3000:1
  • LED Lamps:SMD 3 in 1
  • Driver IC:Constent Current
  • PSU:5V 60A
  • System:Nova
  • Voltage:AC110-240V
  • Transport Package:Plywood Cases
  • Specification:576x768mm
  • Trademark:LEDventure
  • Origin:China
  • HS Code:8528591090
  • Production Capacity:2000sqm,Month

=== Description ===
Overview Product Description

Detailed Photos

Outdoor High Quality P4 Advertising Board LED Display Screen

Outdoor High Quality P4 Advertising Board LED Display Screen

Outdoor High Quality P4 Advertising Board LED Display Screen

Material Quality Level

All of our Product materials we choose all top quality levels, including the SMD, IC components, also the PCB, screws, PSU brands etc, so that during the led screen using, it helps to cut down after sale serive costs, to make sure led display screen stable and less aftersale services.

Outdoor High Quality P4 Advertising Board LED Display Screen
Outdoor High Quality P4 Advertising Board LED Display Screen


Technical Specification



Item

Outdoor High Quality P4 Advertising Board LED Display Screen

Pixel Pitch

4 mm

Pixel Density

62500 pixels/M2

Pixel Configuration

SMD 3 IN 1

Module Size

256x128mm 320x160mm

Module Resolution

64*32pixels 80*40pixels

Min.Viewing Distance

4 meters

Brightness

>6500 nits

Viewing Angle(degree)

≤140°

Average Power Consumption

350 W/M2

Scan Mode

1/8 Scan

Protection Level

IP65/IP54

Cabinet Size

1024x1024mm 960x960mm

Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50HZ/60HZ

Refresh Rate

> 1920hz

Color

65535 Levels

Horizontal/Vertical Viewing Angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

<100 meters

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization



Installation Methods

Outdoor front service back service LED Display screen fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.

Outdoor High Quality P4 Advertising Board LED Display Screen
Outdoor High Quality P4 Advertising Board LED Display Screen






Packing Information

By plywood cases, packing well and easy to load.

Outdoor High Quality P4 Advertising Board LED Display Screen




Certificates

ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.

Outdoor High Quality P4 Advertising Board LED Display Screen
