Full Color Indoor Outdoor LED Curtain TV Display

Hangzhou Awesome Imp&Exp. Co., Ltd. / 2022-06-27

Full Color Indoor Outdoor LED Curtain TV Display

  • Tube Chip Color:Full Color
  • IP Rating:IP65
  • Pixel Pitch:8.9mm
  • Pixel Configuration:1R, 1G, 1B
  • Display Function:Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption:100W,M2

=== Base Info ===

  • Model NO.:P8.9
  • Pixel Density:12546 DOT ,M2
  • Scanning Mode:1,2 Scan
  • Display Type:LED Video Display
  • Application:Advertising
  • Certification:CE, RoHS, UL, CCC, ETL
  • Brightness:3000-3500nits
  • LED Lamps:Epistar
  • Driver IC:Mbi
  • PSU:MW
  • Cabinet:Aluminium
  • Refresh Rate:>1920Hz
  • Contrast Rate:3000:1
  • System:Nova
  • Voltage:AC110-240V
  • IP Rate:IP31
  • Transport Package:Plywood Cases
  • Specification:500x1000mm
  • Trademark:LEDventure
  • Origin:China
  • HS Code:852859109
  • Production Capacity:2000sqm,Month

=== Description ===

Item

Indoor Outdoor Curtain Mesh LED Display Screen

Model Number

P8.9 to P10.4

Pixel Pitch

8.9mm-10.4mm

Pixel Density(pixels/M2)

9216 - 12546 pixels

Pixel Configuration

SMD 3 IN 1

LED Type

NS, SMD

Module size(mm)

250x250mm (options)

Module Resolution(pixels)

24*24 - 28*28 (otions)

Min.Viewing Distance(m)

8-10

Brightness(nits)

3000-3500nits

Viewing Angle(degree)

≤140°

Average Power Consumption(W/M2)

100

Scan Mode

Constant current

Protection Level

IP65

Cabinet Size(mm)

500x1000mm



Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50HZ|60hz

Refresh Rate

> 1920hz

Color

65535 Levels

Horizontal/Vertical viewing angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

<100 meters

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization



Part 5: Installation methods, outdoor front service back service LED Display screen fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.
Full Color Indoor Outdoor LED Curtain TV Display
Full Color Indoor Outdoor LED Curtain TV Display



Part6: Packing information by plywood cases, packing well and easy to load,
Full Color Indoor Outdoor LED Curtain TV Display

Part7: Certificates.

ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.
Full Color Indoor Outdoor LED Curtain TV Display

Part8: About LEDventure.

Full Color Indoor Outdoor LED Curtain TV Display





Part9 : LED display screen installation cases.

Most of our led display exported to Europe with high standards, and small percent to USA and Asia,
Full Color Indoor Outdoor LED Curtain TV Display
Full Color Indoor Outdoor LED Curtain TV Display
