Raw Material for Rail Coach Window Cabinet 400g Woven Roving Cloth

• Shape：Fiberglass Cloth
• Fiber Characteristics：E-Glass
• Diameter of Filaments：13
• Fiber Appearance：Continous Fiber
• Glass Composition：E-Glass
• Product Type：Fiberglass Woven Fabric

=== Base Info ===

• Model NO.：WR400
• Product Code：Ewr400
• Unit Density：400g (+,-5%)
• Product Structure：Fiberglass Roving Aligned in 0,90 Degree in Plain
• Product Design：One Layer, Textiled (Warp Biased)
• MOQ：1000kgs Which in Normal One Pallet
• Suitable Process：Hand Lay up, Compression Molding, Pultrusion etc;
• Applications：Boats & Yachts, Auto Parts, FRP Tanks etc;
• Transport Package：Roll Carton Packing, Per Into Pallets
• Specification：40kgs,roll, 25 rolls in one pallet
• Trademark：ZHONGJIE
• Origin：Changzhou City, Jiangsu Provice, China
• HS Code：7019400000
• Production Capacity：1000tons Per Month

=== Description ===

Basic Info.

Model NO. WR400 Product Code Ewr400 Unit Density 400g (+/-5%) Product Structure Fiberglass Roving Aligned in 0/90 Degree in Plain Product Design One Layer, Textiled (Warp Biased) MOQ 1000kgs Which in Normal One Pallet Suitable Process Hand Lay up, Compression Molding, Pultrusion etc; Applications Boats & Yachts, Auto Parts, FRP Tanks etc; Transport Package Roll Carton Packing, Per Into Pallets Specification 40kgs/roll, 25 rolls in one pallet Trademark ZHONGJIE Origin Changzhou City, Jiangsu Provice, China HS Code 7019400000 Production Capacity 1000tons Per Month

Product Description




• Easy handing, completely and fast wet-out

• High strength in specific directions

• Good moldability

• High productivity

• Uniform tension of parts

  Product Type:	Fiberglass woven fabric
  ZHONGJIE Code:	EWR400
  Unit weight:	400g/m2 (+/-5%)
  Raw material:	Fiberglass direct roving, Polyester yarn
  Technics:	Fiberglass woven fabric is made of firect roving alligned in 0/90 degress as   one layer, then textiled on looms in plain, use   polyester yarn lockup edges
  Woven roving density:	400g/m2 (+/-5%)
  Polyetser yarn:	8g/m2 (+/-5%)
  Gauge as usual:	3.6*3.2 ends/10cm, can be adjusted
  Roving tex as usual:	600/600tex
  Roll packing width:	Normal size is 1000mm, tape size available from 200mm to 3000mm,   depends on customer's real needs
  Mositure content:	≤0.2%
  Sizing/Coupling agent:	Silane
  Combustible Content:	0.4 - 0.6%
  Usage process:	Hand lay up, Compression molding, Filament winding, Pultrusion etc;
  Compatible resins:	Polyester resin, Vinyl resin, Epoxy resin, Phenolic resin etc;
  Application:	Boats & yachts, FRP vessels, Storage tanks, Waterpark slides, Auto parts,   Funitures etc;

Applications refer:
Fiberglass woven fabric widely used in Hand lay up process and applicated to Yachts building, FRP vessles, Waterpart equipments, Auto parts, Storage tanks, Sports apparatus, Railway industry, Furnitures etc;




  Catalog refer:

Product code	Area weight      (g/m² )	Warp/Weft tex refer	Warp/Weft density         (Ends/10cm)	Moisture content              (%)	L.O.I   (%)	Standard roll width              (mm)	Weaving type	Surface fleece available
EWR160	160	66/66	12*12	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue
EWR180	180	66/66	15*13	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue
EWR200TM	200	200/200	5.3*4.6	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue
EWR200	200	200/300	4.6*3.6	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue
EWR270	270	300/300	4.6*4.1	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue
EWR300	300	300/300	5.3*4.6	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue
EWR400	400	600/600	3.6*3.2	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue
EWR500	500	1200/900	2.2*2.6	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue
EWR600	600	1200/1200	2.6*2.4	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue
EWR800	800	2400/2400	1.8*1.6	≤0.2	0.4-0.6	1000	Plain	CSM/Polyester tissue

Factory description:
* Best fiberglass roving and chopped strand supply in China like JUSHI, CTG, CPIC, Shandong fiberglass keeps our products excellent performance and steady in quality

* Well-known in FRP forming process and application keeps our products more outstanding and humanized

* Professional and experienced staff makes our production line more efficient and contineous improvement

* Good management makes our product more competitive in trunout and prices

* More than 45 sets production lines with kinds of machines makes us great production capacity.



Exhibition:
*  JEC Shanghai expo -- Sep., 2016,2017,2018(√)
*  JEC Paris expo --   March., 2017,2018  (√)
*  India composites expo -- Jan., 2019 (√)

*  JEC Paris expo --       March., 2019



Customers:

FAQ:
Q:Are you a factory or trading company?
A:We are a professional fiberglass fabrics and mats manufacturer from 2008, doing kinds of fierglass composites.

Q:Where is your factory located?How can I visit there?
A:Our factory located in Tianning district, Changzhou city, Jiangsu province.About 1.5-2 hours from Shanghai(air port and train station), All our clients, from home or abroad, are warmly welcome to visit us!

Q:What is your annual turn over?
A:In 2017, yearly output more than 18,000 tons, and turnover more than 150,000,000 RMB.

Q:How can you guarantee your quality?
A:Quality is priority.Zhongjie people always attach great importance to quality con trolling from the very beginning to the very end
1.All raw materials we used are from very famous, quality ensured factory like Jushi, CTG, Shandong Fiberglass...
2.Skillful workers care every details in production, packing, transporting.To make sure costomers recived our best made.
3.Quality control department with experienced professers, engineers who from authroized FRP Universities, Reaseach institutes...Etc;

Q:What is your lead time?
A:Usually in 7-10 days for productions and stock always about 3-5 days.
