Outdoor LED APP Highway Project Street Road Solar Motion Sensor Light

• Light Source：LED Lamp
• Lamp Body Material：Aluminum Alloy
• Light Type：Solar
• Color Temperature：Cool White
• Power：30W
• Illumination Time：6h

=== Base Info ===

• Model NO.：NSP30W-APP
• Cell Type：Lithium Battery
• Charging Time (H)：8
• Usage：Garden, Street
• IP Rating：IP65
• Certification：CE, RoHS
• Voltage：12,24V
• With Light Source：With Light Source
• LED Light：30W (Bridgelux, USA)
• Battery：24ah, Lithium Battery
• Solar Panel：60W,18V, Mono
• Controller：MPPT
• Work Mode：Motion Sensor+Dim Light or Constant
• Lumen：3900lm
• Material：Aluminium Alloy
• Installation Height：6-7m
• Spacing：20-25m
• Remote Control：Bluetooth by Mobile Phone APP
• Transport Package：Catons
• Specification：CE, ROHS
• Trademark：NEWSKY POWER
• Origin：China
• HS Code：94054090
• Production Capacity：50000PCS,Month

=== Description ===

Basic Info.

Model NO. NSP30W-APP Cell Type Lithium Battery Charging Time (H) 8 Usage Garden, Street IP Rating IP65 Certification CE, RoHS Voltage 12/24V With Light Source With Light Source LED Light 30W (Bridgelux, USA) Battery 24ah, Lithium Battery Solar Panel 60W/18V, Mono Controller MPPT Work Mode Motion Sensor+Dim Light or Constant Lumen 3900lm Material Aluminium Alloy Installation Height 6-7m Spacing 20-25m Remote Control Bluetooth by Mobile Phone APP Transport Package Catons Specification CE, ROHS Trademark NEWSKY POWER Origin China HS Code 94054090 Production Capacity 50000PCS/Month

Product Description

Product show:


 All in one solar led street lamp for outdoor project
























The installation pictures:





*******************************************************************************************************************************

Product introduction

As a outdoor lighting fixture, the Solar Light is powered by solar energy and designed to offer outstanding quality by utilizing A-class LED beads, integrated optical LED lens, high efficiency mono solar panel, powerful lithium battery, self-developed MPPT controller and patent bluetooth APP system.

Operation principle

The Solar Light is a revolutionary product by utilizing Photovoltaic effect. It isdesigned to constantly absorb solar energy in daylight and convert to electricity, the intelligent
controller could precisely control the charge, discharge and well preserve electricity into the lithium battery. And start to iluminate, which is powered by the lithium battery,
once the iluminance of groundreduced to 15 lux in night time, or solar panel voltage drop to 5V below. The intelligent controller not only protects the battery from over-
charging,over-discharging, but also can control the light switch-on,the time of swicth- on and optimize the brightness effectively according to the real-time environment.

********************************************************************************************************************************


The features of solar street lights NSP series:

1. Solar panel :

LONG-LASTING PERFORMANCE

Anti-aging technology maintains optimum
Performance for 25years
High encapsulation performance

TESTED IN EXTREME CONDITIONS

Salt mist and Ammonia corrosion resistant
Unique design to achieve 8000pa loading

MONO SOLAR CELL

Guarantees better performance in weak light
3-busbar cell technology reduces the series resistance
and helps to boost power output in the module.

2. LED light head:

LED MODULE

A-CLASS LED bead: the advanced lighting technology brings a higher luminous
intensity,

lower thermal resistance and a greater luminaire stability.

this in turn improves the longevity of the LED's promising more long term system
reliability.

Luminous Efficiency>160Lm/W.
Famous brand LED chip.

3. MPPT controller:

CORE TECHNOLOGY

Patent design MPPT controller by our R&D team,
Charging efficiency >95%,
Maximum Power Point Tracking,
Multiple work mode function,
Over-charge, over-discharge, over-heat protection.

4. PIR motion sensor:

EYES OF LIGHT

It detects movement within several meters of the unit and automatically
regulates the output of the LED lamp from a 'dim mode' to 'full-brightness,'
depending upon whether motion is detected. This smart feature preserves
battery power as well as increases .

5. Lithium battery:

LONG LIFETIME

Newsky uses new-generation Lithium batteries which offers 3 times more
storage and power capacity versus conventional Lead Acid batteries.
Lithium batteries are also able to discharge to an incredible 90% without any
damage.
Lifespan over 5years.
Comply with IEC61233.

6. Battery protection:

TEMPERATURE MONITORING

Newsky lithium batteries and smart protection features are up for the
challenge.
Working temperature is -20 degree Celsius to +60 degree Celsius.
Battery temperature can be read by APP mobilephone.

7.  Wireless contection:

BLUETOOTH

It uses a range of wireless connection technologies of Bluetooth to connect
each solar lights.
Smartphone 'end user' App available to download from either the iPhone
or Android app stores that will provide our customers with the ability to
individually communicate with each solar light.

FUNCTIONS

Light control/Time control switch,
Motion sensor/Programming mode,
Rainy days setting,
System status reading,
Power generation statistics,
ON/OFF,
Faulty checking.

The specification of NSP30W-APP:

LED light	30W (Bridgelux,USA)
Battery	24AH, Lithium battery
Solar panel	60W/18V,MONO
Controller	MPPT
Work mode	Motion sensor+dim light or Constant
Lumen	3900Lm
Material	Aluminium alloy
Installation height	6-7m
Spacing	20-25m
Remote control	Bluetooth by Mobile phone APP
N.W/G.W (kg)	13 / 15
Product size(mm)	1126*325*44
Carton size(mm)	1190*380*220
20'/40' Capacity	330/ 732 units

Working Mode

 Light on at dusk, light off at dawn auto. PIR motion sensor detection.

Full power lighting when a human move in the sensors range. 30% power lighting when a human move out.



Do you have the follows doubts?:

1.Pole can be provided?
Normally, we don't supply pole. Most of our clients purchase pole from local, it will be cheaper if without shipping cost.

2.It can work in the cold region?
Charging:0ºC~+60ºC, discharging: -20ºC~+60ºC storage:0ºC~+45ºC

3.How many days it can work in rainy days?
it can work continuously in 3-4 rainy days.

4.OEM is okay?Is it free?
Yes, we supply OEM service. It is free if the order quantity over 100pcs.

5. Battery life and replacement
The lifespan of battery is 5years. It is very easy to replace it.

6. Service after sale
The warranty is 5 years. if has problem, we will ask customer to take photos or video for analysis, if quality problem, we will replace spare part for customer in next order shipment. Or delivered by DHL, but the freight cost will be paid by customer.

7.Express
As it is bulky cargo, the chargeable weight is base on volume,  100*100*100 5000=200KG.
It can be arranged by your DHL, but please confirm if they can deliver it due to battery inside. Normally, we will deliver it by DHL special way through HONGKONG.
Normally, DHL can not accept to deliver. we will deliver it by DHL special way through HONGKONG. Not need DGM report.

8.The angel of it can be changed?
The angle between light and pole is fixed, can not be changed, it is optimized angle.
NSP8W-NSP15W:95°               NSP20W-NSP60W: 105°

9. What is the detection distance?
The detection distance between LED light and human is 10-12 meters.
