P5 Outdoor Full Color LED Display Billboard for Video

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：5mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display
• Average Power Consumption：800W,M2

=== Base Info ===

• Model NO.：p5 outdoor
• Pixel Density：62500
• Scanning Mode：1,16 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, UL, CCC, SGS
• Module Size：320*160mm
• Module Resolution(Dots)：80*40
• Driving Method：1,16 Scanning
• Brightness：>7500nits
• Total Weight：40kg,PCS
• Waterproof：IP43 Front IP65 Rear
• Best Viewing Distance：5-260m
• Best Viewing Angle：120°
• Operating Ambient Humidity：10%--90%
• Life Span：>=100, 000hours
• Transport Package：Anti-Shaking Wooden; Air Flight Case; Carton Case
• Specification：CE, RoHS, SGS
• Trademark：FOXGOLDEN
• Origin：Shenzhen
• HS Code：8528591090
• Production Capacity：5000, 000sqm,Month

=== Description ===
Outdoor P4 DIP Full Color LED Display ScreenNo.ItemP51Pixel pitch5mm2Module size320*160mm3Module resolution(dots)64*324Pixel configuration1R1G1B5Pixel density62500dots/m²6Red wavelength625±2nm7Green wavelength525±2nm8Blue wavelength470±2nm9Colors1677721610Best viewing distance≥5m11Horizontal view angle120°12Maximum power consumption<550W/m²13Brightness≥75000cd/m²14Gray scale16 bits per color15Color temperature6500k16Control methodSynchronization&Asynchronization17Driving method1/4 scanning18Frame frequency60Hz19Refresh frequency≥1920Hz20Working voltageAC220V/110V±10%21IP gradeIP 6522Working temperature-35°C~65°C23MTBF>10,000 hours24Life span>100,000 hours

Product Description

Product Name:Waterproof P5 outdoor advertising LED display board

Why I recommend my customers to choose P4 outdoor Full color LED Display?Please browse four points as follows:
1.High Brightness:We are a professional factory which specialises in producting Outdoor Full color LED Display and LED Module, The Brightness is at least 8000cd/sq.M;

2.Waterproof:The Standard of LED Cabinet  is IP65, which it can protect the rain and dust into the screen.You can fixed install the screen in the rainy day.
3.Wide Used in the outdoor:Widely used in Public,street advertising,shopping mall.Plaza station,Building billboard, expressway,ect
4.Energy Saving and Pro-Environment:Such as P4 outdoor Full color led display,100sq.M;If it is spent for 14hours/day,total 365 days/year.The Energy Saving led display will be save over 10,000 hours than traditional screen each year.

Company Information

FOXGOLDEN GROUP LTD (foxgolden.en.made-in-china.com)is a professional high quality LED display manufacturer. Since 2004,we have been dedicating to the aim that producing high quality products, andnow FOXGOLDEN has been well integrated in terms of R&D, produce, project, capital and marketing.
As one of the professional manufacturers of LED industry, FOXGOLDEN Group Limited has a high quality, professional and strong production team, market-oriented, constantly innovate based company not only manufacturing technology in traditional LED display screen, constantly improve product cost benefit and market competition, but in the special use of the display technology has a breakthrough. The absolute performance and competitive price to the perfect combination, the LED display screen to every corner of the world, the market at home and abroad to win wide reputation.

At present, Foxgolden Group Limited has formed a series of LED display products: outdoor LED display, indoor LED display, portable LED screen, foldable LED screen, soft LED screen rental LED display, stadium LED display, small pitch pixel LED display etc..
    We have 11-year production experience. We have 11-year design experience of offering solution, installation, and after-sales service, etc. Faced with a variety of requirements, we offer flexible diverse solutions. We offer 24-hour all-direction online service. We achieve customer complaint rate below 0.1% and win widespread high praise and good reputation from customers and public.

Packaging & Shipping


Payment terms:	35% deposit before production, 65% balance before shipping -T/T: -Paypal -Western Union -Escrow
Packing:	-Standard Export Carton with fully Polyfoam or Pearl Wool -Flight case; -Anti-shaking wooden case
Shipping:	LED module: 3 to 5 working days upon receiving deposit payment LED display: 5 to 8 working days upon receiving deposit payment
After-Sales-Service:	-Lifetime with professional engineer support. -Within 1-5 year, supply spare parts for free if the machine has quality problem

Our Services
1. Guarantee
(1) We guarantee all our displays, modules, parts for 2 - 5 full year. During this time, we will replace or remand our goods for free if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materials only.

2. Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.

3. Maintenance and Consultation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consultation by E-mail, call, MSN or other ways for free.

4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, UL and so on.

5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.

6. Additional service
(1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free.


Certifications

FAQ

Q1: When is the delivery time?
A1: we will accomplish manufacturing within 10 days after receiving the deposit.

Q2: What is the payment method?
A2: We support a variety of payment methods, the most common is the TT.

Q3: What's the pixel pitch for Outdoor LED Display Screen?
A3: Outdoor (P6mm / P8mm/P10mm)

Q4: Where is it used for?
A4: Outdoor & rental use. Widely used for backdrop of staging event, rental business, live show, concert, etc.

Q5: Can it play HD video?
A5: Yes, it can realize HD video function with Linsn controlling system.

Q6: What's the controlling system?
A6: Our standard controlling system for this model is Linsn, Novastar. Also support other controlling system, like Xixun,TF, Colorlight, etc.

Q7: How about the size of project?
A7: Please offer the size with "width by height" of project. We will offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.

Q8: How about your service?
A8:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
