Best Selling Oral Medical Equipment Wall Mount X-ray Machine

• Certification：CE
• Type：X-Ray Equipment
• Material：Metal, Plastic
• Tube Voltage：70kv
• Tube Current：8mA
• Charger Input Voltage：220V,110V

=== Base Info ===

• Model NO.：XR-3
• Net Weight：57kg
• Exposure Time：0.2-4 Seconds
• Transport Package：Strong Foam, Plastic, Carton
• Specification：Package weight: 60Kg
• Trademark：Xrdent
• Origin：China
• HS Code：90184990
• Production Capacity：1000

=== Description ===

Basic Info.

Model NO. XR-3 Net Weight 57kg Exposure Time 0.2-4 Seconds Transport Package Strong Foam, Plastic, Carton Specification Package weight: 60Kg Trademark Xrdent Origin China HS Code 90184990 Production Capacity 1000

Product Description

Technical Data


Power supply conditions	AC220V±10%, 50HZ, 1KVA
Tube voltage	70KV
Tube current	8mA
Focus size	0.8mm
Total Filtration	2.5mmAL
Exposure time	0.2-4 seconds
Leaked radiation	1 meter away <=0.002mGy/h, (national standard 0.25mGy/h)
Packing size	Host: 152*57*26(cm)
Net weight	Host: 57kg

Features

★Using the international advanced technology,efficient integrated design,high efficiency,low radiation.
★Using microcomputer intelligent control,not only remote controlled exposure,but more powerful function of low voltage alarm and
high voltage protection.
★.Micro focus technology,much more clear image and accurate diagnosis.
★The base has two modes of mobile and fixed ,pneumatic lift soft ensures more convenient for dentist and more comfortable for
patient.
★Can use light room dental film,imaging in one minute,maximum convenient dentist to diagnose.
★Can connect to dental digital imaging system,that is indispensable for clinicians to diagnose and root canal filling.

Precautions

★In order to ensure safety in operation and use, good ground lead must be installed well.
★Because small X-ray machine's thermal capacity is limited, attention should be paid to making the machine work intermittently.
★Only during exposure process this machine will produce X-rays. It won't produce X-rays in power-off state, neither in power-on
state as long as not in exposure.
★If any unforeseen circumstances occur during correct use, operators should cut off the power immediately and stop using the
machine. It cannot be used again until it is overhauled and qualified.
★Before leaving the factory, each X-ray device is equipped with an additional filter plate with the following specifications: 1.0/0.5mm
aluminum sheets.
★Every time when disassembling the machine, disassemble the head first and then other parts.
★Every time after using the machine, recover the cross arm to the highest point, and then place the machine head in an equilibrium
position.
★Every time after using, sterilize and clean beam tube end that contacts the patient with medical alcohol.
★Clean the machine surface with a dry cloth every week and inspect whether the connectors contact well.
★Pay attention to machine maintenance. Check whether the indicator lights, display, rotary knob, switch, and remote control work
normally; whether the X-ray source modules leak oil; whether when X-ray source modules expose produces any abnormal noise; or
whether fixed screws in the mechanical part loose, and the like.
★The rated capacity of the machine is 1.1 kw. Please select power supply or power grid with a power supply capacity greater than
1.5kw. If network voltage in this region is abnormal, we recommend matching 1.5 KW or higher industrial voltage stabilizer, to prevent
damage to the machine and reduced machine life due to abnormal voltage.
