SMD2835 Light Strip Ultra-Narrow with UL CE RoHS LED
Qingdao Haochen Packing Co., Ltd. / 2022-06-27
- Certification:FDA, GS, SAA, VDE, FCC, CCC, LVD, UL, EMC, RoHS, CE
- Power:9.6W
- Emitting Color:2700K,3000K,4000K,5000K,6500K
- Voltage:12V
- IP Rating:IP20
- Product Size:5000*41.15mm
=== Base Info ===
- Model NO.:R0C0GW04A
- Cutting Unit:25mm
- LEDs Pitch:8.33mm
- LEDs Quantity:120PCS,M
- Max. Cascade Length:5m
- Min. Bend Diameter:20mm
- Transport Package:5m,Roll,Bag
- Specification:5m,roll
- Trademark:YOUNICE,ODM
- Origin:China
- HS Code:9405429000
- Production Capacity:100000m,Day
=== Description ===
>80 | 2700K | 855 | 90 |
3000k | 900 | 94 |
4000K | 950 | 99 |
5000K | 950 | 99 |
6500K | 910 | 95 |
Product specifications: Product Size: 5000*41.15mm Cutting Unit: 25mm LEDs Pitch: 8.33mm LEDs Quantity: 120Pcs/m Max. Cascade Length: 5m Min. Bend Diameter : 20mm Mounting: 3M Operating Ambient: -25ºC~45ºC Storage Environment: -25ºC~60ºC / 60% RH
Declaration: -Please drive the led strip with isolated power, and the ripple of the constant voltage source should beless than 5%.; -Please do not bend the strip into an arc with a diameter less than 20mm to ensure the longevity and reliability. -Do not fold it in case any damage of LED beads. -Do not pull the power wire hard to ensure the longevity. Any crash may damage the colloidal surface is prohibited.; -Please make sure the wire is connected to the anode and cathode correctly. The power output should be consistent with the voltage of the strip to avoid damage. -LED lights should be stored in dry, sealed environment. Please only unpack it before usage. Ambient temperature: -20 ºC ~ + -40 ºC.Storage temperature: ---25 ºC ~ + 60 ºC/60%RH.Please use the strips without waterproof within indoor environment with humidity less than 70%. -Please be careful during operation. Do not touch the AC power supply in case of electric shock. -Please leave at least 20% power for the power supply during using to ensure there is enough power supply todrive the product. -Do not use any acid or alkaline adhesives to fix the product (e.g.: glass cement).
