SMD RGB 500 X 500mm Ultra Light Stage Rental LED Video Wall Advertising Board P5.95

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：5.95mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display
• Average Power Consumption：390W,Sqm

=== Base Info ===

• Model NO.：P3.91, P4.8, P5.95, P6.25
• Pixel Density：28224pixels,Sqm
• Scanning Mode：1,5 Scan
• Display Type：LED Video Display
• Application：Stage Performance
• Certification：CE, RoHS, UL, CCC, ETL
• Delivery Time：15~25 Working Days
• Warranty Time：2 Years
• Cabinet Size：500X500mm
• OEM：Yes
• Transport Package：Flight Case, Plywood Case, Carton.
• Specification：CE, ROHS, ISO9001
• Trademark：BST
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：3000 Sqm,Month

=== Description ===
ModelOR-5.95Pixel Pitch5.95mmPixel Density28224 pixels/m2LED TypeSMD2727LED Configuration1R1G1BCabinet Dimension500mmx500mmCabinet Resolution84*84pixelsCabinet Weight13kgCabinet Materialdie casting aluminumIngress Protection(front/rear)IP65/IP54Brightness>6500nitsViewing Angle(H/V)140°/140°Driving Method1/5 ScanFrame Refresh≥ 60HzData Refresh Rate>1500HzGray Scale16bitPower Consumption(avg.)275w/m2Input VoltageAC 110/220±10%,  50~60HzTemperature(operating/storage)-20~50°C / -40~60°CHumidity(operating/storage)10%~90%RH / 10%~85%RHMTBF≥1000hrsLife Span≥50000hrsPixel Failure<0.0003

   High reliability, good flatness

• Control card and ultrathin power supply integrated on a circuit board, no signal cable, enhance stability and reliability greatly.
• With 4 big modules composing a cabinet, internal connection is reduced and product stability is enhanced.

         Control method , Performance

• Usually with synchronous controlling, the software is simple, easy to operate, supporting for multiple languages.
•  Provide customers with unique, new control card and can support both synchronous and asynchronous mode.During  synchronous playing, if the signal is accidentally disconnected,   asynchronous playing will start to use automatically, so the display never stop playing.

• P5.95mm outdoor led display owns high contrast,  refreshing rate and gray scale achieve that when the LED display presents images , there is not any delays, and when rebroadcasting, there is no water ripples,thus achieving fantastic stage effects.

      Energy conservation

• energy conservation and low power consumption save operating costs.
