Garage Equipment Car Prep Bay Room Booth

Jiaxing Topaz Import & Export Co., Ltd. / 2022-06-23

Garage Equipment Car Prep Bay Room Booth

  • After-sales Service:1 Year
  • Warranty:1 Year
  • Type:Preparation
  • Certification:CE
  • Substrate:Steel
  • Brand:Longxiang Brand

=== Base Info ===

  • Model NO.:LX-6100
  • Coating:Powder Coating
  • Airflow Direction:Cross-flow Type
  • Heating Mode:Without Heating
  • Paint Mist Treatment:Dry-type
  • Condition:New
  • Inside Dimension:6300*3450*2800mm(L*W*H)
  • Outside Dimension:7550*3550*3200mm(L*W*H)
  • Basement:Without Basement
  • Fan System:Centrifugal Fan
  • Lighting System:LED Lighting
  • Voltage:380V,220V
  • Total Power:6.4kw
  • Usage:Car Polishing
  • Name:Prep Station
  • Filtering System:Fiber Glass Filter
  • Transport Package:Sea Package
  • Specification:7550*3550*3200mm(L*W*H)
  • Trademark:longxiang brand
  • Origin:China
  • HS Code:8419899090
  • Production Capacity:30 Sets,Months

=== Description ===
                     Specification of Prep-station (LX-6100)        Inside dimension6300×3450×2800mm(L×W×H)Outside dimension7550×3550×3200mm(L×W×H)Basement and floorWithout basementCeiling system6400×3550×520mm(L×W×H),with coaming all sides,lighting between the coaming along the length.The back section of the ceiling is sealed by seal plateGenerator setting typeRear exhaust;square tube frame;white color coated steelExhaust systemGenerator cabin dimension:2290×1200×1800mm(L×W×H);5.5KW one set inner motor centrifugal fan with air capacity 16000m³/h,belt-drive,electric damper to control the air inlet and outlet volumeSeal typeBack side set 50mm EPS,other 3 sides with PVC soft curtain,curtain color:upper part:white,middle part:transparent,lower part:whiteCeiling installationSteel rope hanging or steel pole supporting the roof(optional)Filter systemFiberglass filterLighting system8 units×3pcs=24×36W;side lightsControl systemFan switch,lighting switch and electric damper switchVoltage frequency380V/3PH or 220V/1PH,50HZTotal power 6.4KW
Garage Equipment Car Prep Bay Room BoothGarage Equipment Car Prep Bay Room Booth
