P4 Outdoor Full Color Advertising LED Sign Board

Hangzhou Awesome Imp&Exp. Co., Ltd. / 2022-06-27

P4 Outdoor Full Color Advertising LED Sign Board

  • Tube Chip Color:Full Color
  • IP Rating:IP65
  • Pixel Pitch:4mm
  • Pixel Configuration:1R, 1G, 1B
  • Display Function:Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption:350W , m²

=== Base Info ===

  • Model NO.:P4
  • Pixel Density:62500 Dots,M2
  • Scanning Mode:1,8 Scan
  • Display Type:LED Video Display
  • Application:Advertising
  • Certification:CE, RoHS, UL, CCC, ETL
  • Cabinet Material:Alu,Steel
  • Brightness:5000nits
  • Refresh Rate:>1920Hz
  • Contrast Rate:3000:1
  • Voltage:AC110-240V
  • LED Lamps:Epistar
  • Driver IC:Mbi
  • PSU:MW
  • System:Nova
  • Transport Package:Plywood Cases
  • Specification:960x960mm
  • Trademark:LEDventure
  • Origin:China
  • HS Code:8528591090
  • Production Capacity:2000sqm,Month

=== Description ===

Item

OB Series Outdoor Back Service LED Display Screen

Model Number

OB-P4

Pixel Pitch

4mm

Pixel Density(pixels/M2)

62500 pixels

Pixel Configuration

SMD 3 IN 1

LED Type

NS, SMD

Module Size(mm)

320x160mm

Module Resolution(pixels)

80*40p

Min.Viewing Distance(m)

4

Brightness(nits)

5000nits

Viewing Angle(degree)

≤140°

Average Power Consumption(W/M2)

400

Scan Mode

1/8 Scan

Protection Level

IP65/IP54

Cabinet Size(mm)

960x960mm (Optional)



Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50Hz/60Hz

Refresh Rate

>1920hz

Color

65535 Levels

Horizontal/Vertical viewing angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

<100 meters

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization



Part 5: Installation Methods

Fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.
P4 Outdoor Full Color Advertising LED Sign Board
P4 Outdoor Full Color Advertising LED Sign Board

Part 6: Packing Information

Packed by plywood cases, packing well and easy to load
P4 Outdoor Full Color Advertising LED Sign Board

Part 7: Certificates.

ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.
P4 Outdoor Full Color Advertising LED Sign Board



Part 8: About LEDventure.

P4 Outdoor Full Color Advertising LED Sign BoardPart 9: LED Display Screen Installation Cases.

Most of our led display exported to Europe with high standards, and also exported to USA, South America and Asia
P4 Outdoor Full Color Advertising LED Sign Board
