LED Video Wall for Events Indoor Outdoor P2.6 P2.9 P3.9 P4.8 LED Screen Die-Casting Aluminum Full Color RGB

• Tube Chip Color：Full Color
• Display Function：Video Display
• Pixel Pitch：3.91mm
• Pixel Configuration：1R,1G,1B
• Pixel Density：65400
• System Operating Platform：Window XP, Window 97

=== Base Info ===

• Model NO.：P3.9
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：65
• Certification：CE, RoHS, CCC
• Module Size：250mm X 250mm
• Cabinet Size：500mm X 500mm
• Cabinet Material：Die Casting Aluminium
• Cabinet Weight：8 Kg. Cabinet
• Maintaince：Front Service and Back Service
• Transport Package：Wooden Case , Flight Case
• Specification：CE, RHOS
• Trademark：Noveled
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：1000 Sqm , Week

=== Description ===
Outdoor rental led display 500 x 500  and 500mm x 1000mm serialPixel Pitch3.9mm 4.8mm5.95mm6.25mmPixel density(dot/m2)65400  432642822425600Brightness  (nits)≥5500  ≥5500≥6000≥6000  Drive Method1/16 1/131/10  1/10 Refresh rate (HZ)  ≥1200Cabinet pixel (dot) 128x128 104x10484x84 80x80Cabinet size (mm) 500x500x75Cabinet materialDie-casting Aluminium Cabinet weight8kg/cabinet Screen work Voltage (V) 110~240V/AC Screen power consumption
(W/sqm )Max 750 / Average250Max 800 / Average350 Max 800 / Average 320Max 800 / Average 320  Screen View angle 140°/140°     IP Grade  IP65    Operationg Temperature/Humidity -20~50ºC
 10~90% RH      Storage Temperature/Humidity -40~60ºC
 10~90% RH          Life Time  >50000H      Standard
CertificationCE CCC
Rental  led  display  Advantages and feature

Stable performance, wide applicability, high brightness, high protection grade.
1.High temperature resistant and aging resistant PC materials are applied in the modules to get rid of the mosaic problem even after long time use.
2.High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.
3.The cabinets, featuring great moisture and corrosion proofing, enable themselves to work in all weather conditions.


Front service cabinet with Corner protection  cabinet


Rental  LED Display  Applications
Commercial advertising:Square, Road side, High way, Airport, Wharf, Hotel, Restaurant etc.

Live broadcast:Gym, Stadium, Concert, Sport Match, Competition, Gov publication etc.

Rental business:Entertainment, Wedding, Party etc.


SMT room


Aging and testing area


LED Display other hot sell item


LED display packing and deliver




Led Display Service for customers
 1.We provide pre-sale service in technical consultation, for example, recommending and designing solutions as pre the customers request, which help lower the risk of customers` investing.

2.In the process of production, gloshine follows up the tightly and accept the supervision from the clients.Necessary trainings are also provided to the customers.

3.For the after-sale service,Noveled  takes the great responsibility to collect customers` feedback, inspection and maintains products periodically to ensure solving problems timely.
