Sov Manual Torque Multiplier

• After-sales Service：Limited
• Warranty：Limited
• Type：Wheels Localizer
• Standard：Standard
• Certification：ISO, CE, GS
• Tire Gauges Type：Electronic Tire Pressure Gauge

=== Base Info ===

• Model NO.：FDB series
• Tire Gauges Carry Way：Portable
• Condition：New
• Update Method：by Internet
• Name：Sov Torque Multiplier
• Torque Range：1000-50000 Nm
• Torque Ration：5.5-180
• Square Drive：1,2
• Weight：3.5-55 Kg
• Height：180-360mm
• Diameter：85-275mm
• OEM：Yes
• Stock：Yes
• Payment：T,T
• Transport Package：Toolbox
• Specification：Can customize
• Trademark：SOV, Can OEM
• Origin：Shanghai
• Production Capacity：500

=== Description ===

Basic Info.

Model NO. FDB series Tire Gauges Carry Way Portable Condition New Update Method by Internet Name Sov Torque Multiplier Torque Range 1000-50000 Nm Torque Ration 5.5-180 Square Drive 1/2 Weight 3.5-55 Kg Height 180-360mm Diameter 85-275mm OEM Yes Stock Yes Payment T/T Transport Package Toolbox Specification Can customize Trademark SOV, Can OEM Origin Shanghai Production Capacity 500

Product Description

Product Featrues
Hand torque multipliers are the ideal tools for applications where air and electricity aren't easily accessible. The gearing design allows for a high torque output with minimal input. Commonly used in petrochemical, power generation, transportation, railway construction, shipping and maintenance industries.
Accuracy better than ± 5%.
Precision tightening and loosening of all heavy duty fastening connections.
For operation in combination with a torque wrench.
Torque Multiplication Ratio - low energy input with high torque output.
Compact design allows for operation in space-restricted applications.
Ideal tool for applications where air and electricity aren't easily accessible.
Most models furnished with anti-windup ratchets allowing jobs to be performed easily, efficiently and safely.
Shear pin at input drive protects gear box in case of torque overload.
Constructed with quality steel.
Each tool contains extra shear pins, and torque multiplication selection chart.
Commonly used in petrochemical, power generation, transportation, shipping and maintenance industries.


Features:

• Mechanical torque multiplier could be widely used with many other power tools and applicable for the anti-explosion environment.
• It has high precision and reduction ratio as well as the planetary gear structure and anti-reverse structure.
• The high-tech alloy material planetary gear is used for it, with compact structure, high strength, well abrasive resistance and light weight.
• All the machine parts are finished through CNC machining center, which can ensure the consistency of the products.
• The feature of high quality and maintenance-free saves the maintenance time and cost.

Parameter

Model	SOV-FDB-15	SOV-FDB-20	SOV-FDB-35	SOV-FDB-55	SOV-FDB-75	SOV-FDB-100	SOV-FDB-150	SOV-FDB-200
Max. Torque(Nm)	1500	2000	3500	5500	7500	10000	15000	20000
Transmission ratio	4.8	14	17	19	22	61	74.8	96.8
Input Square(mm)	12.7	12.7	12.7	12.7	12.7	12.7	12.7	12.7
Output Square(mm)	25	25	30	35	40	50	55	60
Bolt Size(mm)	M20-30	M22-36	M30-45	M36-52	M42-60	M52-68	M60-76	M72-80
Nut Size(mm)	S30-46	S32-55	S46-70	S55-80	S65-90	S80-105	S90-115	S105-135

Photos















Packing: All products will be packed with wooden case of outer packing;

Shipping:

1. Small quantity: by international exress, such as DHL, TNT, FEDEX, UPS, etc. depending on the customers' choice. Goods will arrive within 7 days in normal cicumstances;

2. Large quantity: by sea transportation. Goods will arrive in 10~45 days, according to the diatance.

Company Information


SOV is a manufacturer engaged in designing and manufacturing hydraulic cylinders (capacity covers from 5- 1000 tons), synchronous PLC hydraulic system, hydraulic bumps, hydraulic torque wrenches, and electric torque wrenches, and hydraulic components.

Since the establishment in 1995, we successfully transformed from OEM manufacturer for many international brands, to create our own brand SOV, and our factory has been approved by CE, ISO9001:2008 consecutively.

Our customers includes many big Chinese industrial companies, such as China Petroleum, Baosteel, Sinopec, China State Grid, Jiangnan Shipyards,China Railway Construction Corporation. Our synchronous PLC hydraulic system had played a great role in the China high-speed railway constructions. In 2011, our sales revenue reached 30 million USD, making us one of the leaders in the Chinese hydraulic cylinders market especially in the extra-high hydraulic cylinders for industrial area and construction field.

We are a manufacturer in tools, such as:

• Hydraulic cylinders, jacks (5-1000ton), single acting and double acting, hollow plunger;
• Hydraulic/ electric /pneumatic torque wrench (100-72000Nm);
• Hydraulic bolt tensioner (100-11486NM); Hydraulic pullers (5-100 ton)
• Hydraulic pumps, manual and electric type (max up to 3000bar);
• Integrated hydraulic lifting system solutions ( 4-72 points lifting system for house translation or leveling, bridge supporting and tank welding supporting)
• Hydraulic nut and couplings. (M50-Tr1000)

Our products have been widely used in industrial field such as steel plant, cement industry, chemical and refinery, bridge, railway construction and maintenance.

Teams




Our Services

1. 24 hours online service;
2. One year warranty, repair and service for the whole life.
3. Question report will be replied in 48 hours.
4. Quality guaranteed.
