Esavior Professional Manufacturer 200W 20, 000lm Aio Integrated LED Solar Street Garden Light with 3, 000 Circles Lithium Battery with IP67/Ik10/RoHS/CE

• Warranty：3-5 Years
• Light Source：LED Lamp
• Lamp Body Material：Aluminum Alloy
• Light Type：Solar
• Color Temperature：Warm White
• Power：200W

=== Base Info ===

• Model NO.：ISSL-BRZ-200W
• Illumination Time：>10h Full Charge
• Cell Type：LiFePO4 Battery
• Usage：Street, Highway
• IP Rating：IP65
• Certification：CE, RoHS, ISO
• Voltage：12,24V
• With Light Source：With Light Source
• Solar Panel Life-Span：25 Years
• Batteries Capacity/Type：25.6V,42ah(1075.2wh),LiFePO4 Lithium
• Batteries Life-Span：8+ Years (3000 Circles)
• Controller Type：MPPT , Waterproof Class: IP68
• Sensor：Microwave Radar (PIR &Timing as Optional)
• LED Light Source Max LED Power：200W (56LEDs X 4modules)
• Max Lamp Lumen：18000-20000 Lm
• Viewing Angle：140&70degree
• Full Charge Time by Solar：5 Hours
• Discharge Time Bright Mode：More Than 10 Hours
• Discharge Time Dim Mode：More Than 50 Hours
• Mounting Height：10-12m
• Space Between Lights：40-50m
• Transport Package：Ustomary Carton,OEM Acceptable
• Specification：1970*520*55mm
• Trademark：ESAVIOR , ODM
• Origin：Guangzhou, China
• HS Code：9405409000
• Production Capacity：10000 Piece, Per Month

=== Description ===
3 years

DISTRIBUTIONS & IES TYPE




DIALUX SIMULATION REPORT
Street Profile(Tarmac: R3, q0: 0.070)
Pole Height :12m ; Pole Distance :40m; Road Width: 20m; Lanes: 6;



WHY ESAVIOR?

1. 12 years' experience in with global successful project reference on the Solar Lighting field.

2. 13 patents core technologies were awarded to our Solar Street Lights and IoT online Monitoring System for Solar Street Light.

3. ISO 9001/14001, IEC 60598/ IES TM-21 / IES RP-27.3-07 reports were awarded by TUV-SUD besides our existing CE/RoHS/IP66 certificates.

4. More than 100 countries' clients enjoy our solar street led lights, highly praised by UNDP, UNHCR, UNOPS, Red Cross, The World Bank and government.

5. Provides a modern manufacturing base which meets international global solar RD & Inspection Center, has the most advanced inspection equipment and faultless QA system.

SOLAR STREET LIGHT FAQ:

Q1:Does the lamp light on automatically?

A:Yes, it will light on automatically at darkness no matter which mode except "OFF".

Q2:Can I order samples for solar street light?

A:Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.

Q3:What about the lead time?

A:3 workdays for sample, 7-15workdays for batch order(more than 100pcs).

Q4:Do you offer guarantee for the products?

A:Yes, we offer 3-5 years warranty to our products.

Q5:Can the lamp be used in strong wind environment?

A:Of course yes, as we take Aluminum-alloy holder, solid and firm, Zinc plated, anti- rust corrosion.

Q6:What's the difference between Motion sensor and PIR sensor?

A:Motion sensor also called radar sensor, works by emitting high frequency electric wave and detecting people movement.PIR sensor works by detecting environment temperature changing, which usually is 3-5 meters sensor distance.But motion sensor can reach 10 meters distance and be more accurate and sensitive.

Q7:How to deal with the faulty?

A:Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.5%. Secondly, during the guarantee period, we will send replacements with new order for small quantity.


Thank you for your attention!  More details feel free to contact ESAVIOR team!
