P6 Outdoor 7000CD LED Display Video Wall for Advertising Sign

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：6mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display
• Average Power Consumption：300W , m²

=== Base Info ===

• Model NO.：P6
• Pixel Density：27777 Dots ,M2
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, SGS
• LED Lamp：Nation Star ,Kinglight
• IC：Mbi 5124 ,Mbi 5153, Icn 2038 S
• Controller：Nova Star
• Refresh Rate：1920Hz-2038Hz
• Cabinet：960*960mm,768*768mm
• Use Voltage：110-220 V
• Brightness：5500-7000CD,M2
• Maximum Power：1000W,M2
• Warranty：2-5 Years
• Transport Package：Wooden Case
• Specification：192*192mm
• Trademark：honghui
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：3500 Sqm ,Month

=== Description ===
            Pixel Pitch 6 mm Cabinet Size 768*768mm /960*960mmPixel density 27777 dots/m2Color temperature5000K---8000KViewing angleH:140;V:140Dead LED lamp rate≤0.1‰Non-Flatness <0.2mm   Module interval   <0.2mm    Packaging Gross Weight(KG)   55 kg (Estimated data)    Packaging dimension   1*1*1.2 m (6cabinet in one case)    Maximal power/m2    800 W/m2    Brightness adjusted   256 grade by auto-optic/color &8 grade by hand    Input signal   RF,S-video,RGB,RGBHV,YUV,YC&Composition,etc    Life-span    ≥1 00,000 hours    MTBF    5,000 hours    Frame frequency   25 - 60 Hz / s    Refresh rate   ≥2,000 Hz  / s    Single Input(with video processor)   HDMI, DVI, VGA, RF, S-Video, RGB,
RGBHV, YUV, YC&Composition, etc.    Control Distance   120 m (no repeating); Optical fiber
transmission: 0.5km- 10km    Systems Operating Platform   Windows XP, Win 7, Win8, Win10
2.Product Details :




3.Application Place :

Business
 Supermarket, Shopping malls, Exclusive agency, Chain shops, Hotels, Restaurants, Travel agencies,Etc.

Public Places

Subway, Airports, Bookstores, Exhibition halls, Stadiums, Museums, Convention centers,   Commercial buildings, Meeting rooms,Post offices, Hospital, Schools

Financial

Banks,  Insurance companies,Securities companies

Entertainments

Movie theaters, Night Clubs, Stage, Party, Wedding scene
