P5 Big Outdoor Advertising LED Board Video Wall Sign LED Display Screen

• IP Rating：IP65
• Pixel Pitch：5mm

=== Base Info ===

• Model NO.：QCP5
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：350W , m²
• Pixel Density：40000DOT,Sqm
• Scanning Mode：1,8 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, CCC, ISO, SGS
• Brightness：6500CD
• Refresh Rate：1920Hz,3840Hz
• Best View Distance：>5m
• Life Time：100, 000hours
• Cabinet Material：Steel,Die Casting
• Cabinet Size：960mm*960mm
• Warranty：2 Years
• Transport Package：Wooden Case Packing
• Specification：320mm*160mm
• Trademark：QC
• Origin：China, Guangzhou
• HS Code：8528591090
• Production Capacity：3000 Square Meters , Month
• Package size per unit product：110.00cm * 30.00cm * 116.00cm
• Gross weight per unit product：55.000kg

=== Description ===

Basic Info.

Model NO. QCP5 Pixel Configuration 1R, 1G, 1B Display Function Video Display, Image & Text Display, Text Display, Market Display Average Power Consumption 350W / m² Pixel Density 40000DOT/Sqm Scanning Mode 1/8 Scan Display Type LED Video Display Application Advertising Certification CE, RoHS, CCC, ISO, SGS Brightness 6500CD Refresh Rate 1920Hz/3840Hz Best View Distance >5m Life Time 100, 000hours Cabinet Material Steel/Die Casting Cabinet Size 960mm*960mm Warranty 2 Years Transport Package Wooden Case Packing Specification 320mm*160mm Trademark QC Origin China, Guangzhou HS Code 8528591090 Production Capacity 3000 Square Meters / Month

Packaging & Delivery

Package size per unit product 110.00cm * 30.00cm * 116.00cm Gross weight per unit product 55.000kg

Product Description

P5 Outdoor Full Color LED Display Screen boards

Technical Parameters

Items	P5 Outdoor Full Color LED Display screen
Pitch  size	5mm
Module  size	320mm*160mm
Panel  pixel(dots)	64*32
Pixel  configuration	1Red, 1Green, 1Blue SMD2727
Color  scale	65536degree/16777216colors
Pixel  density	40000pixels/square  meter
View  angle(H/V)	140/140degree
Brightness	≥ 6500nits
View  distance	5--200m
Power  consumption	100-1200W/square meter
Net  weight	less than 45kg/square  meter
Operating  temperature	_ 25° C~+60° C
Operating  humidity	10%_ 95%RH
Life  time	≥ 100, 000hours
Exchange  frame  speed	> 150frames  per  second
Refresh  frame  frequency	1920Hz
Control  distance	120m  (without  relay), single  mode  fiber: 20000m, multi  mode  fiber: 500m-20km
Power	110V/220V/380V± 15%  50Hz
Operating  system	Windows
Drive  mode	constant  current  driving
Display  mode	VGA640X480_ VGA1600X1024
Input  Voltage	AC220v/50Herts
Protections  for  outdoor  display	IP65
Accepting  signal	PAL/NTSC/SECAM, S-Video; VGA; RGB; Composite  Video; SDI

Other products:
Indoor fixed LED screen: P1.53,P1.875,P2,P2.5, P3, P4, P5, P6, P8, P10
Indoor rental LED screen: P2.5,P2.976,P3, P3.91, P4, P4.8, P4.81, P5, P6
Outdoor fixed LED screen: P2.5, P3, P4, P5, P6, P6.67,P8, P10
Outdoor rental LED screen:P3, P3.91, P4, P4.8, P4.81, P5, P6, P8, P10
Small pitch LED screen: P1.25, P1.53
Front service maintenance LED screen: P6.67, P8, P10
Stadium perimeter LED screen: P4, P5, P6, P8, P10
LED poster player: P1.875, P2.5, P3, P4, P5, P6, P8, P10


Company Information

Packing & Shipping

Payment terms: By T/T in advance, 30% deposit and the balance 70% before shipment.

Delivery time:15-20days

Warranty time:2 years,offer the free spare parts(module & power supply) in advance.After guarantee term,
still supply spare parts with charging only materials cost.

Packing:Standard wooden case packing free,flight case packing

FAQ

1. Diversified products :

Varieties of models for outdoor/indoor LED display screens,and customized cabinets available,meet all requirements and win more profits for customers.



 2. Experienced&Professional:

10 years manufacturing experience on LED displays, professional workmanship & design.



 3. Best raw materials:

 High quality,high brightness and long life span.



 4. Competitive price:

 100% factory price,competitive and reasonable price.



 5. Strict quality control:

 100% testing before packing , make sure our quality before delivery.



 6. Quality gurantee:

 Life span of LED display screens is more than 100,000 hours

 All our LED displays have CE,FCC,RoHS certificates.



7. Prompt &Professional service :

Any inquires will be replied within 24 hours in working days and you'll get helpful suggestions from us.
