Overview
Product Description
P2.5 P3 P4 P5 Indoor Outdoor LED Video display Wall for advertising is popular for indoor advertising media, such as in airport, shopping mall, shows etc, it is light weight design, HD resolution with high contract rate, also refresh rate is good level to ensure image quality, hot sale pixels are P2.5mm and P3mm.
Detailed Photos Indoor led video wall detail images included hardware
All of our Product materials we choose all top quality levels, including the SMD, IC components, also the PCB, screws, PSU brands etc, so that during the led screen using, it helps to cut down after sale serive costs, to make sure led display screen stable and less aftersale services.
Item
Model Number
Pixel Pitch
3mm
Pixel Density
111111 pixels/M2
Pixel Configuration
1R1G1B
LED Type
Epistar, SMD
Module Size
320x160mm
Module Resolution
104*52pixel
Min.Viewing Distance
3meters
Brightness
800nits
Viewing Angle(degree)
≤140°
Average Power Consumption
400W/M2
Scan Mode
1/16 Scan
Protection Level
IP31
Cabinet Size
640x480mm 640x640mm 960x480mm
Color Temperature
The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements
Input Voltage
AC110-240V, 50HZ|60hz
Refresh Rate
> 1920hz
Color
65535 Levels
Horizontal/Vertical Viewing Angle
<140°
Gray Scale
16 bits
Effective Communication Distance(without relay)
Lifespan
≥100,000 hours
Environment Temperature
Storage: -40°C~+85°C , Operation: -20 °C~+45°C
Blind Spot Rate
<0.0001(led display industry standard is less than 0.0003)
Control Mode
Video frequency synchronization
Installation Methods
Indoor led video wall available fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.
By plywood cases, packing well and easy to load.
ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.
