RGB Outdoor P10 P8 P5 320X160 LED Display Module

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：8mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：220W , m²

=== Base Info ===

• Model NO.：p8 led module
• Pixel Density：15625dots,M2
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, CCC, ISO9001
• Product Name：Outdoor LED Display P8-4s
• Driver IC：Mbi5124
• Bightness CD/Sqm：5000CD,M2
• Grey Scale：65536 Degree
• Life Time：More 100, 000 Hours (80%)
• Mtbf：More 50, 000 Hours
• Operating Temperature：-30~-60t
• Humidity：10%-95%
• Color Temperature：6500-9500K
• Refresh Rate：1920Hz
• Transport Package：The Box Packaging
• Specification：256*128mm
• Trademark：hongking
• Origin：China
• HS Code：8528591090
• Production Capacity：5000 Sqm,Year

=== Description ===
Module ParameterItemSpecification ParameterPixel Pitch, Resolution rate, size8mm, 32*16 Dots, 256*128mmPixel color, Pixel LED1R1G1B, SMD3535Working voltage, Module PowerDC5V, 48WDriving IC, Driving wayMBI5124, 1/4SHUBQP-HUB75(MRV220)-V1.1




Cabinet:

• Cold Rolled Steel or aluminiumRefresh Rate300-3000HZ adjustableLED Life100,000 hoursSupply VoltageAC220V/50HZ; AC110V/60HZOperating Temperature-20ºC ~ +50ºCOperating Humidity10% - 90%Gray ScaleRed, Green and Blue each 16KDisplay Color4096 BillionIP RatingFront IP65Display CapabilityText, Graph and VideoNotes:Specifications are for reference only.

  Professional production:
  Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen

  ---------------------------------------------------------------------






  Why choose  HONGKING?

      HONGKING is a professional manufacturer of LED display screens over 6 years. We have strong R&D to ensure high end products with user-friendly design .
      The prices are very competitive due to our large-scale procurement of raw material.   We can help you to win more orders if you are distributors.End users will also be satisfied with our quality and price.
      We have CE, FCC and Rohs certificates. Our products are exported over 85 countries .We have rich experience in handling all possible problems when you import goods from China .
      We have a wide variety of products for you to choose from .All products are strictly tested before release to market and we test every LED screen 72 hours before delivery.
      Our sales are well trained to offer professional advice on your specific projects. Processional engineers are on standby, can offer guidance, on site technical support as requested.
      We offer 2-3 years warranty and life time maintenance .Even when warranty time expires , we only charge material costs

   about the installation commissioning ;
  after project confirm ,we will provide detailed  construction install drawing
  when we finished screen will aging tesing 72 hours ;
  you can come and visit make sure quality then we can training
  if you wont come we can provide remote control .
  if necessary ,we can also appoint engineers to your site ;

  Display the installation and debugging, not as difficult as you think;
  After the factory production is completed, we will debug the product well,
  Send connected pictures and drawings to you at the same time;

  Thanks and best regards

  Tom xie
